SKU:

SP-C-WEB

Controller, EcoStruxure Security Expert, web enabled security purpose controller

$3,405.60 INC GST

Qty:

Available for Shipping : 16-Dec-2025

Controller, EcoStruxure Security Expert, web enabled security purpose controller

Be the first to review this product

Manufacturer: Schneider Electric

Delivery date: 16-Dec-2025

Instruction sheet

Product Page Link

Product Data Sheet

Controller, EcoStruxure Security Expert, web enabled security purpose controller

Products specifications

Attribute name	Attribute value
Main
Number of port	2 RS485/Wiegand
Device application	remote monitoring, control
Width	90 mm
[In] rated current	120 mA
Product weight	376 g
Relative humidity	0-93 % non-condensing
Output current	<= 50 mA open collector output, <= 7 A form C relay, 1500 mA alarm (inrush), 1.1 A alarm (continuous), 0.7 A auxiliary output
Ambient air temperature for storage	-10-85 °C
Colour	black
Directives	2014/30/EU - electromagnetic compatibility, 2014/35/EU - low voltage directive
Function available	firmware update
Height	60 mm
Range	EcoStruxure Security Expert
Number of inputs	18 discrete
Product or component type	controller
Ambient air temperature for operation	0-50 °C
Number of outputs	1 alarm output, 2 auxiliary output, 4 open collector NPN output, 2 form C relay output
[Us] rated supply voltage	11...14 V DC
Product certifications	RCM, ACMA, CE
Complementary
Supply	power supply, <3.4 A
Load type	resistive load for relay output, inductive load for relay output
Integrated connection type	Ethernet, modem, RS485
Length	156 mm
Maximum output current	1.6 A, alarm output, 1.1 A, auxiliary output
Local signalling	8 green/red LED, input status, 2 red LED, relay ON, 1 green LED, buzzer, 2 red LED, reader data, 1 green LED, modem, 1 green LED, ethernet connection, 1 red LED, fault, 1 green LED, status, 1 green LED, power
Number of alarms	32 alarm areas
Communication port protocol	UDP/IP 10/100 Mbit/s
Standards	CAN/ULC-S319-05, FCC CFR 47 part 15: class A, CAN/ULC-S559-04, CAN/ULC-S304-06, UL 1610, UL 294, ICES-003: class A, EN 50131-6:2008, EN 50131-3:2009, EN 50131-1:2006
Mounting support	DIN rail
Encryption protocol	AES (Advanced Encryption Standard) conforming to NIST
Discrete input type	reader input, high security monitored input
Product brand	Schneider Electric
Environment
Environmental characteristic	indoor use

Output voltage	9 V DC
Packing Units
Unit Type of Package 1	1
Number of Units in Package 1	1
Package 1 Height	18.4 cm
Package 1 Width	11 cm
Package 1 Length	6.6 cm
Package 1 Weight	400 g
