Picture of V292 Globe Valve, 2-Way, PN25, Flanged, DN100, 130 Kvs, Nodular Iron Body and Stainless Steel Trim, Stem Down Closed.
SKU:

7219262010

V292 Globe Valve, 2-Way, PN25, Flanged, DN100, 130 Kvs, Nodular Iron Body and Stainless Steel Trim, Stem Down Closed.

$7,109.30 INC GST
Available for Shipping : 18-Dec-2025
V292 Globe Valve, 2-Way, PN25, Flanged, DN100, 130 Kvs, Nodular Iron Body and Stainless Steel Trim, Stem Down Closed.
  • Stainless Steel trim for long service life
  • 30 mm stroke for precise control of low flows
  • Service Kit and Stem heater accessories available
  • U Bolt Actuator mounting accepts M800, M1500, M3000 and M700 SR actuators
Be the first to review this product
Manufacturer: Schneider Electric
Delivery date: 18-Dec-2025
Catalog
Product Page Link
Product Data Sheet
The V292 is a high pressure flanged globe valve for demanding heating and cooling applications. The valve use a stainless steel plug for high close off pressures with a low actuator force. Stainless Steel plug and seat provides a high pressure differential capability and a low leakage. The crown plug provides precise fluid control with a rangeability of 5:1 and is of a self cleaning design for reliable operation. Valve size: DN100, Flow capacity/Kvs: 130 m³/h. Constructed and flanged to a PN25 pressure class. ΔPm of maximum 14 Kpa. PTFE Seals provide a working temperature range of -1 °C to 15 °C 5 mm stroke ensures high controllability, Equal percentage flow characteristic ensures high controllability at low opening degrees. Length: 29 mm, Height 23 mm, Width: 185 mm, Weight: 16.7 Kg. Service Kit (main gland seal): 1182.

Products specifications

Attribute name Attribute value
Main
Operating fluid temperature -10-150 °C
Body material nodular cast iron EN-JS 1025
Seating seal material Port A:metal to metal
Seat leakage Port A: Less than 0.05 % of kvs
Product or component type valve
Targeted region Australia., Asia Pacific., Europe
Valve connection size DN100 (ISO 7005-2)
Seat material Port A: stainless steel AISI 420
Medium compatibility Water, Glycol 50 %, Glycol 30 %, Glycol 25 %
Control valve rangeability greater than 50:1
Plug material stainless steel AISI 420
Valve product series V292
Flow coefficient 130 kvs, 150.31 cv
Stem flow action Stem down closed
Valve configuration 2-Way
Stem movement linear
Pressure fluid max delta P normal life 22 psi
Valve type globe
Valve model V292/100/130
Packing material PTFE (polytetrafluoroethylene)
Valve connection type flanged
Stem seal material PTFE (polytetrafluoroethylene)
Flow characteristic equal percentage
Trim material stainless steel
Stroke length 30 mm
Stem material stainless steel AISI 420
Pipe size 100 mm
Pressure class PN25
Body size 100 mm (4 in)
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 34.5 cm
Package 1 Width 41.0 cm
Package 1 Length 23.5 cm
Package 1 Weight 39.6 kg
