Picture of discrete output module Modicon Momentum - 16 O solid state
SKU:

170ADO74050

discrete output module Modicon Momentum - 16 O solid state

$3,440.80 INC GST
Availability: Please contact our sales team on 1300 724 622.
discrete output module Modicon Momentum - 16 O solid state
Be the first to review this product
Manufacturer: Schneider Electric
Environmental Disclosure
Circularity Profile
Declaration of conformity
User guide
Product Page Link
Product Data Sheet

Products specifications

Attribute name Attribute value
Main
Protective treatment TC
Short-circuit protection internal fuse, 5 A slow-blow per group
Discrete output number 16
Discrete output voltage 230 V AC
Product or component type discrete output base AC
Current per channel 0.5 A
Range of product Modicon Momentum automation platform
Group of channels 2 groups of 8 outputs
Discrete output type triac
Complementary
Isolation between channels and bus 1780 V AC for 1 minute
Depth 47.5 mm
Width 125 mm
Output overload protection internal fuse
Local signalling 16 LEDs for channel status
Maximum leakage current 2.4 mA 230 V AC
Net weight 0.284 kg
Discrete output current 8 A per module, 4 A per group
Marking CE
Surge current 5 A for 3 cycles, 15 A for 1 cycle, 10 A for 2 cycles
Current consumption 65 mA at 230 V AC
Response time 1/2 x 1/f (= 0.5 of one line cycle) from state 1 to state 0, 1/2 x 1/f (= 0.5 of one line cycle) from state 0 to state 1
Maximum voltage drop <1.5 V 0.5 A at state 1
Terminals description PLC n°1 (3)OUT_DIS#3, (15)OUT_DIS#15, (14)OUT_DIS#14, (16)OUT_DIS#16, (12)OUT_DIS#12, TB, (4)OUT_DIS#4, (13)OUT_DIS#13, (11)OUT_DIS#11, (1L+)PW, (1N)PW, (9)OUT_DIS#9, (5)OUT_DIS#5, (2)OUT_DIS#2, (8)OUT_DIS#8, (1)OUT_DIS#1, (6)OUT_DIS#6, (10)OUT_DIS#10, (7)OUT_DIS#7
[Ue] rated operational voltage 230 V AC
Minimum output current 30 mA
Height 141.5 mm
Power dissipation 7.5 W maximum, 6 W typical
Environment
Operating altitude <= 5000 m
Resistance to electrostatic discharge 8 kV on air conforming to IEC 801-2, 4 kV contact conforming to IEC 801-2
Relative humidity 95-95 % without condensation
Ambient air temperature for storage -40-85 °C
Resistance to electromagnetic fields 10 V/m 80...1000 MHz conforming to IEC 801-3
Ambient air temperature for operation 0-60 °C
Product certifications FM Class 1 Division 2, CSA, UL
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 9.5 cm
Package 1 Width 18.0 cm
Package 1 Length 26.0 cm
Package 1 Weight 482.0 g
Unit Type of Package 2 2
Number of Units in Package 2 6
Package 2 Height 30.0 cm
Package 2 Width 30.0 cm
Package 2 Length 40.0 cm
Package 2 Weight 2.892 kg
