Picture of discrete output module Modicon Momentum - 16 O solid state
SKU:

170ADO54050

discrete output module Modicon Momentum - 16 O solid state

$3,273.82 INC GST
Available for Shipping : 20-Jan-2026
discrete output module Modicon Momentum - 16 O solid state
Be the first to review this product
Manufacturer: Schneider Electric
Delivery date: 20-Jan-2026
Environmental Disclosure
Circularity Profile
Declaration of conformity
User guide
Product Page Link
Product Data Sheet
This output module is part of the Modicon Momentum range, an offer of controller and IP20 monoblock I/Os for distributed control architecture. This discrete output base AC module offers 2 groups of 8 outputs, 16 discrete outputs with triac type. It offers discrete output voltage of 120V AC. There is an isolation between channels and bus at 1780V AC. It features 16 LEDs for channel status signaling. Its dimensions are 125mm (width) x 47.5mm (depth) x 141.5mm (height). It weighs 0.284kg. The main application of this module is infrastructures and energy, material handling, simple machine control. This product is certified by CE, FM Class 1 Division 2, CSA and UL. It is suitable for wall mount. Momentum is a flexible, modular family of components that easily snaps together and can be configured for a wide range of distributed I/O and control applications. System with 4 fundamental components that easily snap together in various combinations to form versatile control systems or sub-systems.

Products specifications

Attribute name Attribute value
Main
Protective treatment TC
Short-circuit protection internal fuse, 5 A slow-blow per group
Discrete output number 16
Discrete output voltage 120 V AC
Product or component type discrete output base AC
Current per channel 0.5 A
Range of product Modicon Momentum automation platform
Group of channels 2 groups of 8 outputs
Discrete output type triac
Complementary
Isolation between channels and bus 1780 V AC for 1 minute
Depth 47.5 mm
Width 125 mm
Output overload protection internal fuse
Local signalling 16 LEDs for channel status
Maximum leakage current 1.9 mA 120 V AC
Net weight 0.284 kg
Discrete output current 8 A per module, 4 A per group
Marking CE
Surge current 5 A for 3 cycles, 15 A for 1 cycle, 10 A for 2 cycles
Current consumption 125 mA at 120 V AC
Response time 1/2 x 1/f (= 0.5 of one line cycle) from state 1 to state 0, 1/2 x 1/f (= 0.5 of one line cycle) from state 0 to state 1
Maximum voltage drop <1.5 V 0.5 A at state 1
Terminals description PLC n°1 (16)OUT_DIS#16, (14)OUT_DIS#14, (7)OUT_DIS#7, (6)OUT_DIS#6, (11)OUT_DIS#11, (2)OUT_DIS#2, (15)OUT_DIS#15, (13)OUT_DIS#13, (5)OUT_DIS#5, (1L+)PW, (9)OUT_DIS#9, (1)OUT_DIS#1, (1N)PW, (10)OUT_DIS#10, TB, (8)OUT_DIS#8, (12)OUT_DIS#12, (4)OUT_DIS#4, (3)OUT_DIS#3
[Ue] rated operational voltage 120 V AC
Minimum output current 30 mA
Height 141.5 mm
Power dissipation 6 W typical, 7.5 W maximum
Environment
Operating altitude <= 5000 m
Resistance to electrostatic discharge 8 kV on air conforming to IEC 801-2, 4 kV contact conforming to IEC 801-2
Relative humidity 95-95 % without condensation
Ambient air temperature for storage -40-85 °C
Resistance to electromagnetic fields 10 V/m 80...1000 MHz conforming to IEC 801-3
Ambient air temperature for operation 0-60 °C
Product certifications FM Class 1 Division 2, UL, CSA
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 9.000 cm
Package 1 Width 18.000 cm
Package 1 Length 25.500 cm
Package 1 Weight 494.000 g
Unit Type of Package 2 2
Number of Units in Package 2 6
Package 2 Height 30.000 cm
Package 2 Width 30.000 cm
Package 2 Length 40.000 cm
Package 2 Weight 2.964 kg
