Picture of discrete output module Modicon Momentum - 16 O solid state
SKU:

170ADO34000

discrete output module Modicon Momentum - 16 O solid state

$1,664.74 INC GST
Available for Shipping : 15-Dec-2025
discrete output module Modicon Momentum - 16 O solid state
Be the first to review this product
Manufacturer: Schneider Electric
Delivery date: 15-Dec-2025
Circularity Profile
Instruction sheet
Environmental Disclosure
Declaration of conformity
User guide
Product Page Link
Product Data Sheet
This output module is part of the Modicon Momentum range, an offer of controller and IP20 monoblock I/Os for distributed control architecture. This discrete output base DC module offers 2 groups of 8 outputs, 16 discrete outputs with solid state switch type. It offers discrete output voltage of 24V DC. There is an isolation between channels and bus at 500V AC. It features 16 LEDs for channel status signaling. Its dimensions are 125mm (width) x 47.5mm (depth) x 141.5mm (height). It weighs 0.21kg. The main application of this module is infrastructures and energy, material handling, simple machine control. This product is certified by CE, FM Class 1 Division 2, CSA and UL. It is suitable for wall mount. Momentum is a flexible, modular family of components that easily snaps together and can be configured for a wide range of distributed I/O and control applications. System with 4 fundamental components that easily snap together in various combinations to form versatile control systems or sub-systems.

Products specifications

Attribute name Attribute value
Main
Protective treatment TC
Short-circuit protection outputs electronically protected
Discrete output number 16
Discrete output voltage 24 V DC
Product or component type discrete output base DC
Current per channel 0.5 A
Range of product Modicon Momentum automation platform
Group of channels 2 groups of 8 outputs
Discrete output type solid state switch
Complementary
Isolation between channels and bus 500 V AC
Depth 47.5 mm
Width 125 mm
Output overload protection outputs electronically protected
Local signalling 16 LEDs for channel status
Maximum leakage current 1 mA 24 V DC
Net weight 0.21 kg
Discrete output current 8 A per module, 4 A per group
Marking CE
Surge current 5 A during 1 ms
Current consumption 250 mA at 24 V DC
Response time 0.1 ms from state 1 to state 0, 0.1 ms from state 0 to state 1
Maximum voltage drop <0.5 V 0.5 A at state 1
Terminals description PLC n°1 (1L+)PW_POS, (3)OUT_DIS#3, (9)OUT_DIS#9, (7)OUT_DIS#7, (13)OUT_DIS#13, TB, (11)OUT_DIS#11, (10)OUT_DIS#10, (2)OUT_DIS#2, (6)OUT_DIS#6, (16)OUT_DIS#16, (4)OUT_DIS#4, (8)OUT_DIS#8, (12)OUT_DIS#12, (M-)PW_NEG, (15)OUT_DIS#15, (1)OUT_DIS#1, (5)OUT_DIS#5, (L+)PW_POS, (2L+)PW_POS, (14)OUT_DIS#14
[Ue] rated operational voltage 24 V DC
Height 141.5 mm
Power dissipation 4.5 W maximum, 3.5 W typical
Environment
Operating altitude <= 5000 m
Resistance to electrostatic discharge 8 kV on air conforming to IEC 801-2, 4 kV contact conforming to IEC 801-2
Relative humidity 95-95 % without condensation
Ambient air temperature for storage -40-85 °C
Resistance to electromagnetic fields 10 V/m 80...1000 MHz conforming to IEC 801-3
Ambient air temperature for operation 0-60 °C
Product certifications CSA, FM Class 1 Division 2, UL
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 5.7 cm
Package 1 Width 18.2 cm
Package 1 Length 26.0 cm
Package 1 Weight 384.0 g
Unit Type of Package 2 2
Number of Units in Package 2 10
Package 2 Height 30 cm
Package 2 Width 30 cm
Package 2 Length 40 cm
Package 2 Weight 3.84 kg
Unit Type of Package 3 3
Number of Units in Package 3 80
Package 3 Height 75.0 cm
Package 3 Width 40.0 cm
Package 3 Length 80.0 cm
Package 3 Weight 43.9 kg
