Picture of discrete input module Modicon Quantum - 32 I - 10..60 V DC
SKU:

140DDI85300

discrete input module Modicon Quantum - 32 I - 10..60 V DC

$4,121.15 INC GST
Availability: Please contact our sales team on 1300 724 622.
discrete input module Modicon Quantum - 32 I - 10..60 V DC
Be the first to review this product
Manufacturer: Schneider Electric
Instruction sheet
Declaration of conformity
Catalog
CAD
User guide
Product Page Link
Product Data Sheet

Products specifications

Attribute name Attribute value
Main
Discrete input number 32
Product or component type dc discrete input modules
Range of product Modicon Quantum automation platform
Complementary
Input voltage 60 V 1-5 mA DC, 48 V 2-15 mA DC, 24 V 6-30 mA DC, 12 V 5-10 mA DC
Module format standard
Local signalling 32 LEDs (green) for input status, 1 LED (green) for bus communication is present (Active)
Addressing requirement 2 input words
Bus current requirement 300 mA
Voltage state 1 guaranteed 45...60 V 60 V - 15...20 %, 34...48 V 48 V - 15...20 %, 11...24 V 24 V - 15...20 %, 9...12 V 12 V +/- 5 %
Net weight 0.295 kg
Voltage state 0 guaranteed 0...5 V 24 V - 15...20 %, 0...12.5 V 60 V - 15...20 %, 0...10 V 48 V - 15...20 %, 0...1.8 V 12 V +/- 5 %
Input voltage limits 10...60 V
Marking CE
Isolation between group 700 Vrms DC for 1 minute
Response time 4 ms from state 1 to state 0, 4 ms from state 0 to state 1
Absolute maximum voltage 75 V
Isolation between group and bus 2500 Vrms DC for 1 minute
Group of channels 4
Switching frequency <= 100 Hz
Power dissipation 1 W + (0.25 x number of points on)
Logic input positive (sink)
Environment
Operating altitude <= 5000 m
Resistance to electrostatic discharge 8 kV on air conforming to IEC 801-2, 4 kV contact conforming to IEC 801-2
Relative humidity 95-95 % without condensation
Ambient air temperature for storage -40-85 °C
Standards UL 508, CSA C22.2 No 142, EN/IEC 61131-2
Resistance to electromagnetic fields 10 V/m 80-2000 MHz conforming to IEC 801-3
Ambient air temperature for operation 0-60 °C
Product certifications hazardous location class 1, division 2, CE, CSA, EAC, UL, Merchant Navy, RCM
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 16.3 cm
Package 1 Width 4.5 cm
Package 1 Length 31.2 cm
Package 1 Weight 428.0 g
