Picture of discrete input module Modicon Quantum - 24 I - 125 V DC
SKU:

140DDI67300

discrete input module Modicon Quantum - 24 I - 125 V DC

$4,063.49 INC GST
Availability: Please contact our sales team on 1300 724 622.
discrete input module Modicon Quantum - 24 I - 125 V DC
Be the first to review this product
Manufacturer: Schneider Electric
CAD
User guide
Instruction sheet
Declaration of conformity
Catalog
Product Page Link
Product Data Sheet

Products specifications

Attribute name Attribute value
Main
Discrete input number 24
Product or component type dc discrete input modules
Range of product Modicon Quantum automation platform
Complementary
Input voltage 125 V 2.5-2.5 mA DC
Module format standard
Local signalling 24 LEDs (green) for input status, 1 LED (red) for external fault detected (F), 1 LED (green) for bus communication is present (Active)
Addressing requirement 2 input words
Bus current requirement 200 mA
Net weight 0.3 kg
Input voltage limits 88...150 V
Marking CE
Isolation between group 700 Vrms DC for 1 minute
Response time 0.7 ms from state 1 to state 0, 0.7 ms from state 0 to state 1
Absolute maximum voltage 156.25 V including ripple
Isolation between group and bus 2500 Vrms DC for 1 minute
Group of channels 3
Power dissipation 1 W + (0.62 x number of points on)
Logic input positive (sink)
Environment
Operating altitude <= 5000 m
Resistance to electrostatic discharge 8 kV on air conforming to IEC 801-2, 4 kV contact conforming to IEC 801-2
Relative humidity 95-95 % without condensation
Ambient air temperature for storage -40-85 °C
Standards CSA C22.2 No 142, UL 508
Resistance to electromagnetic fields 10 V/m 80-2000 MHz conforming to IEC 801-3
Ambient air temperature for operation 0-60 °C
Product certifications FM Class 1 Division 2, C-Tick
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 16.3 cm
Package 1 Width 4.5 cm
Package 1 Length 31.2 cm
Package 1 Weight 452 g
Unit Type of Package 2 2
Number of Units in Package 2 7
Package 2 Height 30 cm
Package 2 Width 30 cm
Package 2 Length 40 cm
Package 2 Weight 3.108 kg
