Picture of discrete output module Modicon Quantum - 16 O - 20..56 V AC
SKU:

140DAO84220

discrete output module Modicon Quantum - 16 O - 20..56 V AC

$3,315.42 INC GST
Available for Shipping : 02-Feb-2026
discrete output module Modicon Quantum - 16 O - 20..56 V AC
Be the first to review this product
Manufacturer: Schneider Electric
Delivery date: 02-Feb-2026
Instruction sheet
Declaration of conformity
CAD
Catalog
User guide
Product Page Link
Product Data Sheet

Products specifications

Attribute name Attribute value
Main
Discrete output number 16
Product or component type AC discrete output modules
Range of product Modicon Quantum automation platform
Complementary
Supply frequency 47...63 Hz
Module format standard
Protection type internal output protection by 5 A fuse, internal by RC filter
DV/dt 400 V/ms
Local signalling 16 LEDs (green) for input status, 1 LED (red) for external fault detected (F), 1 LED (green) for bus communication is present (Active)
Fault indication loss of field power, blown fuse
Addressing requirement 1 output word
Bus current requirement 350 mA
Absolute maximum output 111 Vrms for 1.3 s AC, 63 Vrms for 10 s AC, 100 Vrms 1 cycle AC
Net weight 0.45 kg
Marking CE
Surge current 30 A during 3 cycles per group, 25 A during 2 cycles per group, 45 A during 1 cycle per group
Discrete output voltage 20...56 V AC
Response time <= 0.5 ms at state 1 to state 0, <= 0.5 ms at state 0 to state 1
Maximum voltage drop 1.5 V
Group of channels 4 groups of 4 channels
Maximum load current 4 A rms 20...56 V per output, 4 A rms per group, 16 A rms per module
Power dissipation 1.85 + (1.1 V x total module load current)
Environment
Operating altitude <= 5000 m
Relative humidity 95-95 % without condensation
Ambient air temperature for storage -40-85 °C
Electromagnetic compatibility susceptibility to electromagnetic fields - test level: 10 V/m (80...1000 MHz) conforming to IEC 801-3, electrostatic discharge immunity test - test level: 8 kV (air discharge) conforming to IEC 801-2, electrostatic discharge immunity test - test level: 4 kV (contact discharge) conforming to IEC 801-2
Standards CSA C22.2 No 142, UL 508
Ambient air temperature for operation 0-60 °C
Product certifications cUL, FM Class 1 Division 2
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 16.3 cm
Package 1 Width 4.5 cm
Package 1 Length 31.2 cm
Package 1 Weight 644.0 g
