Picture of analog output module Modicon Quantum - 8 O multirange
SKU:

140ACO13000

analog output module Modicon Quantum - 8 O multirange

$10,569.19 INC GST
Availability: Please contact our sales team on 1300 724 622.
analog output module Modicon Quantum - 8 O multirange
Be the first to review this product
Manufacturer: Schneider Electric
Declaration of conformity
User guide
Catalog
Instruction sheet
CAD
Product Page Link
Product Data Sheet

Products specifications

Attribute name Attribute value
Main
Product or component type analogue output module
Range of product Modicon Quantum automation platform
Complementary
Isolation between channels and bus 1780 V for 1 minute AC
Update time 5 ms
Module format standard
Local signalling 8 LEDs (red) for channel fault, 8 LEDs (green) for channel is turned on, 1 LED (red) for external fault, 1 LED (green) for bus communication is present (Active)
Addressing requirement 8 output words
Absolute accuracy error +/- 0.2 % of full scale at 25 °C
Bus current requirement 550 mA
Analogue output number 8
Maximum power dissipation in W 5 W
External power requirement 6...30 V
Analogue output range 4...20 mA 0...4095 counts, 4...20 mA 0...16000 counts, 0...25 mA 0...25000 counts, 0...20 mA 0...20000 counts
Net weight 0.3 kg
Accuracy drift according to temperature 0.007 % of full scale/°C maximum, 0.004 % of full scale/°C typical
Marking CE
Linearity +/- 4 µA 4...20 mA 0...16000 counts, +/- 4 µA 0...25 mA 0...25000 counts, +/- 4 µA 0...20 mA 0...20000 counts, +/- 12 µA 4...20 mA 0...4095 counts
Loop voltage 6-30 V DC
Setting time 1.6 ms to 5% of the final value, 3.2 ms to +/-0.1% of the final value
Maximum voltage drop <30 V 25 mA
Fault type open circuit 4...20 mA
Environment
Operating altitude <= 5000 m
Relative humidity 95-95 % without condensation
Ambient air temperature for storage -40-85 °C
Standards CSA C22.2 No 142, UL 508
Resistance to electromagnetic fields 10 V/m 80-2000 MHz conforming to IEC 801-3
Ambient air temperature for operation 0-60 °C
Product certifications FM Class 1 Division 2, cUL
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 4.800 cm
Package 1 Width 16.700 cm
Package 1 Length 31.500 cm
Package 1 Weight 438.000 g
