SKU:

140ESI06210

ASCII serial link module Modicon Quantum - 2 RS232C port

$8,494.20 INC GST

Qty:

Availability: Please contact our sales team on 1300 724 622.

ASCII serial link module Modicon Quantum - 2 RS232C port

Manufacturer: Schneider Electric

Declaration of conformity

Catalog

CAD

User guide

Instruction sheet

Product Page Link

Product Data Sheet

Attribute name	Attribute value
Main
Software name	Unity Pro > V2, ProWORX NxT > V2, ProWORX 32 > V2, Concept > V2
Range of product	Modicon Quantum automation platform
Product or component type	ASCII serial link module
Complementary
Number of messages	255
Product compatibility	all Quantum CPU
Module format	standard
Message nesting	8 levels
Addressing requirement	12 input words, 12 output words
Bus current requirement	300 mA
Maximum power dissipation in W	2 W
Memory capacity	32 kB RAM, 128 kB flash
Clock	with calendar clock
Mode of transmission	ASCII
Maximum cable distance between devices	<20 m
Transmission rate	19.2 kbit/s
Number of port	2 RS232C non isolated conforming to DIN 66020
Product specific application	for standard applications
Net weight	0.3 kg
Buffer size	255 I bytes/255 O bytes
Message length	127 characters + 1 checksum maximum
Electrical connection	2 connectors SUB-D 9
Environment
Relative humidity	95-95 % without condensation
Ambient air temperature for storage	-40-85 °C
Resistance to electromagnetic fields	10 V/m 80...1000 MHz conforming to IEC 801-3
Ambient air temperature for operation	0-60 °C
Operating altitude	<= 5000 m
Packing Units
Unit Type of Package 1	1
Number of Units in Package 1	1
Package 1 Height	5.0 cm
Package 1 Width	16.5 cm
Package 1 Length	31.5 cm
Package 1 Weight	423.0 g
