Picture of Single contact block, Harmony XAC, spring return, 2 speed, spring return, front mounting, 2NO+1NC
Picture of Single contact block, Harmony XAC, spring return, 2 speed, spring return, front mounting, 2NO+1NC
Picture of Single contact block, Harmony XAC, spring return, 2 speed, spring return, front mounting, 2NO+1NC
Picture of Single contact block, Harmony XAC, spring return, 2 speed, spring return, front mounting, 2NO+1NC
Picture of Single contact block, Harmony XAC, spring return, 2 speed, spring return, front mounting, 2NO+1NC
Picture of Single contact block, Harmony XAC, spring return, 2 speed, spring return, front mounting, 2NO+1NC
SKU:

XENG1191

Single contact block, Harmony XAC, spring return, 2 speed, spring return, front mounting, 2NO+1NC

Old price: $112.64 INC GST
$87.86 INC GST
Available for Shipping : 15-Dec-2025
Single contact block, Harmony XAC, spring return, 2 speed, spring return, front mounting, 2NO+1NC
Be the first to review this product
Manufacturer: Schneider Electric
Delivery date: 15-Dec-2025
Image of product in real life situation
Image of product in real life situation
Catalog
Instruction sheet
Declaration of conformity
Environmental Disclosure
Product Page Link
Product Data Sheet
This Harmony XAC, contact block uses screw-clamp terminals and has 2 x NO + 1 x NC contact. This contact block allows fast and easy replacement and configuration of your push buttons and selector switches. It is easily installed and replaced on XACM and XACB pendant control stations and connects to control circuits with simple screw-clamp connections. It protects operators from unexpected contact with live circuits thanks to its IP20 protection index. It has clear labelling of the contact wiring and terminals names on the side of the block. Vibration resistant screw clamp connection terminals ensure high vibration resistance making product suitable installation on high impact machine.

Products specifications

Attribute name Attribute value
Main
Product compatibility XACA9...head, XACA
Electrical circuit type control circuit
Contact operation staggered, slow-break
Contact block application 2-speed
Contact block type single
Range of product Harmony XAC
Type of operator spring return
Contacts type and composition 1 NC + 2 NO
Component name XENG
Product or component type contact block
Mounting of block front mounting
Complementary
Contact code designation Q600 DC-13, Ue = 600 V, Ie = 0.1 A conforming to IEC 60947-5-1 appendix A, Q600 DC-13, Ue = 250 V, Ie = 0.27 A conforming to IEC 60947-5-1 appendix A, A600 AC-15, Ue = 600 V, Ie = 1.2 A conforming to IEC 60947-5-1 appendix A, A600 AC-15, Ue = 240 V, Ie = 3 A conforming to IEC 60947-5-1 appendix A
Operating force 18 N
Mechanical durability 1000000 cycles
Short-circuit protection 10 A fuse protection by cartridge fuse type gG
Maximum resistance across terminals 25 MOhm
Rated operational power in W 65 W DC-13 for 1000000 cycles, operating rate <60 cyc/mn at 24 V, load factor = 0.5 (inductive load) conforming to IEC 60947-5-1 appendix C, 48 W DC-13 for 1000000 cycles, operating rate <60 cyc/mn at 48 V, load factor = 0.5 (inductive load) conforming to IEC 60947-5-1 appendix C, 40 W DC-13 for 1000000 cycles, operating rate <60 cyc/mn at 120 V, load factor = 0.5 (inductive load) conforming to IEC 60947-5-1 appendix C
[Ui] rated insulation voltage 600 V (pollution degree 3) conforming to IEC 60947-1
Connections - terminals screw clamp terminals, 1 x 0.5...2 x 1.5 mm² with cable end, screw clamp terminals, 1 x 0.5...1 x 2.5 mm² without cable end
[Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60947-1
Net weight 0.04 kg
[Ithe] conventional enclosed thermal current 10 A
Terminals description ISO n°1 (13-14)NO, (33-34)NO_CL, (21-22)NC
Environment
Ambient air temperature for storage -40-70 °C
Shock resistance 100 gn conforming to IEC 60068-2-27
Ambient air temperature for operation -25-70 °C
Overvoltage category class II conforming to IEC 61140
Vibration resistance 15 gn (f= 10-500 Hz) conforming to IEC 60068-2-6
Standards CSA C22.2 No 14, EN/IEC 60947-5-1, UL 508
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 3.0 cm
Package 1 Width 4.0 cm
Package 1 Length 5.5 cm
Package 1 Weight 42.0 g
Unit Type of Package 2 2
Number of Units in Package 2 100
Package 2 Height 15.0 cm
Package 2 Width 30.0 cm
Package 2 Length 40.0 cm
Package 2 Weight 4.55 kg
Unit Type of Package 3 3
Number of Units in Package 3 1600
Package 3 Height 77.0 cm
Package 3 Width 80.0 cm
Package 3 Length 60.0 cm
Package 3 Weight 81.3 kg
