Picture of bus extension kit, Modicon STB, BOS internal
SKU:

STBXBE1300K

bus extension kit, Modicon STB, BOS internal

$536.36 INC GST
Available for Shipping : 08-Dec-2025
bus extension kit, Modicon STB, BOS internal
Be the first to review this product
Manufacturer: Schneider Electric
Delivery date: 08-Dec-2025
Declaration of conformity
Circularity Profile
Environmental Disclosure
User guide
Catalog
Product Page Link
Product Data Sheet
This bus extension kit is part of the Modicon STB range, an offer of IP20 modular distributed I/Os on multiple networks and fieldbus. This BOS internal bus extension kit is furnished with 2-pin removable connector for power supply and FireWire for interface. It is a BOS module with rated supply voltage of 24V DC and input current of 400mA. It is an IP20 rated product. It is suitable for packaging, bottling, assembly, distribution, textile, printing and semiconductor machines. This product is certified by CE, FM Class 1 Division 2, CSA, UL. It is compatible with standard STB modules. The kit includes STBXTS1120, 2-terminal screw type connector, STBXBA2300 size 2 base, STBXTS2120, 2-terminal spring clamp connector and STBXBE1300 BOS module. Advantys distributed I/O solutions are simple, open and flexible, meeting needs in every stage of the product life cycle. For distributed connection to sensors and actuators from a PLC with prefabricated cables.

Products specifications

Attribute name Attribute value
Main
Range of product Modicon STB distributed I/O solution
Product or component type BOS internal bus extension kit
Complementary
Product compatibility standard STB modules
Supply voltage limits 19.2-30 V
Electrical connection Firewire for interface, 2 pins for removable connector for power supply
Marking CE
Output voltage type DC
Output voltage 5.25 V +/- 0.21 % logic bus
[Us] rated supply voltage 24 V
Kit composition STBXTS1120, 2-terminal screw type connector, STBXBA2300 size 2 base, STBXTS2120, 2-terminal spring clamp connector, STBXBE1300 BOS module
Overvoltage category II
Supply circuit type DC
Power supply output current 1.2 A
Input current 400 mA
Mounting location beginning of extension segment
Environment
Relative humidity 95-95 % at 60-60 °C without condensation
Ambient air temperature for storage -40-85 °C
Pollution degree 2 conforming to IEC 60664-1
IP degree of protection IP20 conforming to IEC 61131-2 class 1
Electromagnetic compatibility immunity to electromagnetic interference conforming to IEC 61131-2
Operating altitude <= 2000 m
Vibration resistance +/-0.35 mm at 10-58 Hz, 5 gn at 58-150 Hz on 35 x 15 mm symmetrical DIN rail, 3 gn at 58-150 Hz on 35 x 7.5 mm symmetrical DIN rail
Shock resistance 30 gn for 11 ms conforming to IEC 88 reference 2-27
Product certifications CSA, UL, FM Class 1 Division 2
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 2.500 cm
Package 1 Width 8.000 cm
Package 1 Length 13.000 cm
Package 1 Weight 125.000 g
Unit Type of Package 2 2
Number of Units in Package 2 42
Package 2 Height 15.000 cm
Package 2 Width 30.000 cm
Package 2 Length 40.000 cm
Package 2 Weight 5.670 kg
