Picture of TeSys Deca, suppressor module, RC circuit, 24...48V AC
SKU:

LA4DA1E

TeSys Deca, suppressor module, RC circuit, 24...48V AC

Old price: $109.89 INC GST
$69.23 INC GST
Availability: Please contact our sales team on 1300 724 622.
TeSys Deca, suppressor module, RC circuit, 24...48V AC
  • Meet the need for coil protection for TeSys Deca contactor
  • New modern look & feel of all machines
  • Digital customer experience for technical documents
  • Easier to install.
Be the first to review this product
Manufacturer: Schneider Electric
Environmental Disclosure
Product Page Link
Product Data Sheet
This product is TeSys Deca suppressor module, for LC1D09-D38 (3P) contactors. It is used with 24-48V AC control circuit voltage, It is provided with RC protection limiting the transient voltage to 3Uc max. It mounts on top of contactor, clip-on fixing and connection. It is Green Premium compliant (RoHS/REACh).

Products specifications

Attribute name Attribute value
Main
Device short name LA4D
Product compatibility 3P LC1D80...D150
Range TeSys
Product or component type suppressor module
Range of product TeSys Deca
Complementary
Suppressor technology RC circuit
Compatibility code LA4D
Mounting mode by screws
Maximum peak voltage 3 Uc
[Uc] control circuit voltage 24...48 V AC 50/60 Hz
Environment
Ambient air temperature for storage -40-80 °C
Ambient air temperature for operation -25-55 °C
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 2.8 cm
Package 1 Width 4.2 cm
Package 1 Length 5.1 cm
Package 1 Weight 16.0 g
Unit Type of Package 2 2
Number of Units in Package 2 78
Package 2 Height 15 cm
Package 2 Width 15 cm
Package 2 Length 40 cm
Package 2 Weight 1.449 kg
