SKU:

GV2RT05

TeSys Deca, Motor circuit breaker,TeSys Deca,3P,0.63-1A,thermal magnetic,screw clamp terminals,toggle handle

Old price: $391.60 INC GST

Price: $246.71 INC GST

Qty:

Available for Shipping : 12-Jan-2026

Product Selector

TeSys Deca, Motor circuit breaker,TeSys Deca,3P,0.63-1A,thermal magnetic,screw clamp terminals,toggle handle

New modern look & feel of all machines

Wide range of GVs: Magnetic, thermal magnetic, different sizes (GV2,GV3,GV4)

Easier to install and operate with multi-standard screws

Safe and long-lasting power connection with EverLink terminals

Digital customer experience for technical documents

Maintenance guide via EcoStruxureTM Facility Expect

Be the first to review this product

Manufacturer: Schneider Electric

Delivery date: 12-Jan-2026

Circularity Profile

Environmental Disclosure

Instruction sheet

Catalog

Declaration of conformity

Product Page Link

Product Data Sheet

TeSys GV motor circuit breaker, 3 poles (3P), 1A/690V, for high starting current peak motor applications 0.25-0.37kW@400V. It provides a thermal-magnetic protection with a thermal setting range 0.63-1A, a magnetic tripping level at 20xIn, high breaking capacity Icu 100kA. Connection by screw clamp terminals. Start-stop control by toggle guaranteed for 100 000 cycles AC-3. It can be used for protection of 3-phase transformer applications. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh).

Products specifications

Attribute name	Attribute value
Main
Device short name	GV2RT
Device application	transformer, motor protection
Range	TeSys Deca
Range of product	TeSys GV2
Trip unit technology	thermal-magnetic
Product name	TeSys Deca, TeSys GV2
Product or component type	motor circuit breaker
Complementary
Compatibility code	GV2RT
Mechanical durability	100000 cycles
Tightening torque	1.7 N.m - on screw clamp terminal
Suitability for isolation	yes conforming to IEC 60947-1 § 7-1-6
Breaking capacity	100 kA Icu at 690 V AC 50/60 Hz conforming to IEC 60947-2, 100 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-2, 100 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2, 100 kA Icu at 400/415 V AC 50/60 Hz conforming to IEC 60947-2, 100 kA Icu at 220/230 V AC 50/60 Hz conforming to IEC 60947-2
Electrical durability	100000 cycles for AC-3e at 415 V In, 100000 cycles for AC-3 at 415 V In
Power dissipation per pole	2.5 W
Control type	toggle
Fixing mode	panel: screwed (with adaptor plate), 35 mm symmetrical DIN rail: clipped
Maximum operating rate	25 cyc/h
Magnetic tripping current	22-22 A
Height	89 mm
Network frequency	50/60 Hz conforming to IEC 60947-4-1
Depth	78.5 mm
Width	45 mm
Poles description	3P
Direct connector	without
Thermal protection adjustment range	0.63-1 A conforming to IEC 60947-4-1
[Ui] rated insulation voltage	690 V AC 50/60 Hz conforming to IEC 60947-2
[Uimp] rated impulse withstand voltage	6 kV conforming to IEC 60947-2
Utilisation category	AC-3e conforming to IEC 60947-4-1, AC-3 conforming to IEC 60947-4-1, category A conforming to IEC 60947-2
Motor power kW	1-1 kW at 690 V AC 50/60 Hz transformer protection, 0.63-0.63 kW at 500 V AC 50/60 Hz transformer protection, 0.63-0.63 kW at 440 V AC 50/60 Hz transformer protection, 0.55-0.55 kW at 690 V AC 50/60 Hz motor protection high peak current, 0.37-0.37 kW at 500 V AC 50/60 Hz motor protection high peak current, 0.37-0.37 kW at 440 V AC 50/60 Hz motor protection high peak current, 0.25-0.25 kW at 440 V AC 50/60 Hz motor protection high peak current, 0.37-0.37 kW at 400/415 V AC 50/60 Hz motor protection high peak current, 0.25-0.25 kW at 400/415 V AC 50/60 Hz motor protection high peak current, 0.12-0.12 kW at 220/230 V AC 50/60 Hz motor protection high peak current, 0.09-0.09 kW at 220/230 V AC 50/60 Hz motor protection high peak current
[Ith] conventional free air thermal current	1 A conforming to IEC 60947-4-1
Network type	AC
Rated duty	continuous conforming to IEC 60947-4-1
[Ue] rated operational voltage	690 V AC 50/60 Hz conforming to IEC 60947-2
[In] rated current	1 A
Environment
Fire resistance	960 °C conforming to IEC 60695-2-11
IP degree of protection	IP20 conforming to IEC 60529
Ambient air temperature for storage	-40-80 °C
Climatic withstand	conforming to IACS E10
Ambient air temperature for operation	-20-60 °C
Mechanical robustness	vibrations: 5 Gn, 5...150 Hz, shocks: 30 Gn for 11 ms
IK degree of protection	IK04
Operating altitude	2000 m
Standards	EN/IEC 60947-4-1, EN/IEC 60947-2
Product certifications	UKCA, BV, LROS (Lloyds register of shipping), EAC, CSA, UL, CCC
Packing Units
Unit Type of Package 1	1
Number of Units in Package 1	1
Package 1 Height	4.800 cm
Package 1 Width	9.300 cm
Package 1 Length	8.700 cm
Package 1 Weight	229.000 g
Unit Type of Package 2	2
Number of Units in Package 2	24
Package 2 Height	15.000 cm
Package 2 Width	30.000 cm
Package 2 Length	40.000 cm
Package 2 Weight	5.799 kg
Unit Type of Package 3	3
Number of Units in Package 3	384
Package 3 Height	75.000 cm
Package 3 Width	60.000 cm
Package 3 Length	80.000 cm
Package 3 Weight	102.564 kg
