Picture of Communication adaptor, Modicon Momentum automation platform, Profibus DP, 9.6 to 12Mbit/s, twisted pair cable
SKU:

170DNT11000

Communication adaptor, Modicon Momentum automation platform, Profibus DP, 9.6 to 12Mbit/s, twisted pair cable

$864.60 INC GST
Availability: Please contact our sales team on 1300 724 622.
Communication adaptor, Modicon Momentum automation platform, Profibus DP, 9.6 to 12Mbit/s, twisted pair cable
  • Provides foundation for the rest of momentum control system
  • Serve as the mounting base
  • From I/O base supply
  • Fail safe
  • Switch selectable addressing
  • Twisted pair transmission support medium
  • IP20 degree of protection
  • Wide range of operating temperature from 0°C to 60°C
Be the first to review this product
Manufacturer: Schneider Electric
Declaration of conformity
User guide
Instruction sheet
Catalog
Product Page Link
Product Data Sheet
This product is part of the Modicon Momentum range, an offer of controller and IP20 monoblock I/Os for distributed control architecture. This Profibus DP communication adaptor supports ring and multidrop topology. The adaptor offers twisted pair transmission support medium and 9.6Mbps to 12Mbps data rate. It is equipped with 2 x 9-way SUB-D connectors for electrical connection. It supports 9.6kbps to 12Mbps communication rate with twisted pair cable media and distance of 1200m (4000ft). It is an IP20 rated product. It weighs 0.07kg. The main application of this module is infrastructures and energy, material handling, simple machine control. This product is certified by CE, UL and CSA. Momentum is a flexible, modular family of fundamental components that easily snap together and can be configured for a wide range of distributed I/O and control applications. The Profibus DP communication adapter for the Momentum I/O product line provides a direct connection to the Profibus DP communication network for the full family of Momentum I/O modules.

Products specifications

Attribute name Attribute value
Main
Method of access master/slave
Range of product Modicon Momentum automation platform
Transmission rate 9.6...12 Mbit/s
Communication port protocol Profibus DP
Transmission support medium twisted pair
Product or component type Profibus DP communication adaptor
Complementary
Module format standard
Topology multidrop, ring
Control parameter CRC-16
Marking CE
Number of devices per segment 0-126
Addressing switch selectable
Maximum cable distance between devices 1200 m
Local signalling 1 LED (green) for bus fault (BF)
Net weight 0.07 kg
Fail state fail safe
Supply from I/O base
Electrical connection 1 connector SUB-D 9
Environment
IP degree of protection IP20
Protective treatment TC
Resistance to electrostatic discharge 8 kV on air conforming to IEC 801-2, 4 kV contact conforming to IEC 801-2
Relative humidity 95-95 % without condensation
Ambient air temperature for storage -40-85 °C
Resistance to electromagnetic fields 10 V/m 80...1000 MHz conforming to IEC 801-3
Ambient air temperature for operation 0-60 °C
Operating altitude <= 5000 m
Product certifications UL, CSA
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 5.5 cm
Package 1 Width 17.9 cm
Package 1 Length 25.9 cm
Package 1 Weight 188.0 g
