Picture of Clipsal Iconic, Grid Switch, Horizontal Twin, 15A, 250V
SKU:

3025/15G

Clipsal Iconic, Grid Switch, Horizontal Twin, 15A, 250V

Old price: $89.32 INC GST
$107.18 INC GST
Available for Shipping : 25-Jun-2025
Clipsal Iconic, Grid Switch, Horizontal Twin, 15A, 250V
  • Protective flaps prevent access to screws after installation
  • Sockets have internal shutters providing more protection
  • Tapping pad for spirit level
  • Green indicator so you know when it is switched on
  • Hole centre indicators
  • Captive terminal screws to prevent them from coming out
  • 84mm mounting centres fit standard mounting accessories
  • Pre mounted screws for faster fit off
  • Metal plate for additional robustness
  • Large terminals accommodating up to 4 x 2.5mm cables
Be the first to review this product
Manufacturer: Clipsal
Product environmental
Product Page Link
Product Data Sheet
The Clipsal Iconic Horizontal Twin Power Point Grid has been designed in Australia with protection in mind. The protective flaps clearly indicate they should only be opened by certified electricians, and once installed the grid is ready for a Clipsal Iconic skin to complete the power point.

Products specifications

Attribute name Attribute value
Main
Outlet poles configuration 2P + E with shutter
Device presentation mechanism with fixing frame
Outlet standard Australian
Range Clipsal Iconic
Product or component type switched socket
Complementary
Number of power socket outlets 2
Quantity per set set of 10
Sale per indivisible quantity 1
Wire stripping length 16 mm
Height 71 mm
Connections - terminals 3 screw terminals
Electrical durability 10000 cycles
Number of rocker 2
Material POM (polyoxymethylene): shutter, PP (polypropylene): rocker, PC (polycarbonate): fixing frame
Net weight 0.094 kg
Type of packing polybag
Clamping connection capacity 1 x 2.5...4 x 2.5 mm² for flexible cable(s), 1 x 2.5...4 x 2.5 mm² for stranded cable(s), 1 x 2.5...4 x 2.5 mm² for rigid cable(s)
Range compatibility Clipsal Iconic cover frame
Device mounting flush
Embedding depth 18 mm
Ground lug position straight 180° position
Surface finish matt
Screwdriver shape Philips No 2, square drive no 1 (SQ1)
Depth 26 mm
Width 115 mm
Installation direction horizontal
Outlet standard description with earthing contact
Outlet standard deviation Australian/New Zealand
Rated current 15 A at 250 V AC 50 Hz
Fixing mode by screw
Environment
Relative humidity 10-95 %
Product certifications RCM
Ambient air temperature for operation 0-45 °C
Standards AS/NZS 3112
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 3.1 cm
Package 1 Width 7.1 cm
Package 1 Length 11.6 cm
Package 1 Weight 71 g
