SKU:

5126080000

STP Series telescopic pipe temperature sensor, STP660, probe 100-300 mm, Satchwell compatible

$176.59 INC GST

Qty:

Available for Shipping : 16-Feb-2026

STP Series telescopic pipe temperature sensor, STP660, probe 100-300 mm, Satchwell compatible

Be the first to review this product

Manufacturer: Schneider Electric

Delivery date: 16-Feb-2026

Catalog

Product Page Link

Product Data Sheet

Temperature measurement is given through use of a passive thermistor output suitable for connection to the appropriate controller system type. It is intended for immersion mounting in pipe systems with a separate pocket/well, and has an extendable telescopic probe.

Products specifications

Attribute name	Attribute value
Main
IP degree of protection	IP65
Device application	pipe immersion
Depth	45 mm
Colour	black and green
Output type	resistive output
Width	85 mm
Sensor type	10 kOhm thermistor w/resistor & 11 kOhm Shunt temperature
Location	plant room
Product or component type	sensor
Type of measurement	temperature
Targeted region	Asia Pacific., Europe
Mounting support	pipe
Range of product	STP
Height	66 mm
Complementary
Measurement accuracy	0...25 °C +/- 0.3 °C
Diameter	6 mm probe:
Material	polyamide: enclosure
Length	100-300 mm for side probe
Environment
Product certifications	CE
Measurement range	- 10...120 °C
Packing Units
Unit Type of Package 1	1
Number of Units in Package 1	1
Package 1 Height	20.4 cm
Package 1 Width	9.4 cm
Package 1 Length	7 cm
Package 1 Weight	200 g
