SKU:

5123108010

STP Series temperature sensor, STP100-200, pipe, 200mm, TAC Vista And TAC Xenta compatible

$87.16 INC GST

Qty:

Available for Shipping : 15-Dec-2025

STP Series temperature sensor, STP100-200, pipe, 200mm, TAC Vista And TAC Xenta compatible

Manufacturer: Schneider Electric

Delivery date: 15-Dec-2025

Catalog

Instruction sheet

Product Page Link

Product Data Sheet

SpaceLogic STP 100 is an immersion temperature sensor. These sensors are designed for immersion mounting in pipe systems with a separate pocket/well.

Attribute name	Attribute value
Main
IP degree of protection	IP65
Device application	pipe immersion
Product compatibility	Vista
Depth	44 mm
Colour	black and green
Output type	resistive output
Width	65 mm
Sensor type	1.8 kOhm NTC temperature
Net weight	0.11 kg
Location	plant room
Ambient air temperature for operation	-10-150 °C
Product or component type	sensor
Type of measurement	temperature
Targeted region	Europe, Asia Pacific.
Standards	EN 50081-1, EN 50082-2
Mounting support	pipe
Range of product	STP100
Height	84 mm
Complementary
Measurement accuracy	0...25 °C +/- 0.3 °C
Number of cables	1 <0.02 m
Material	stainless steel: immersion tube, PA (polyamide): connection box
Connections - terminals	wire (AWG 24...AWG 18)
Type of installation	immersion
Length	200-200 mm for side sensor
Former part number	5123108010
Time constant	24000 ms stainless steel PN 25 without contact paste, 23000 ms brass PN 16 without contact paste, 20000 ms stainless steel PN 25 with contact paste, 19000 ms brass PN 16 with contact paste
Environment
Product certifications	CE
Packing Units
Unit Type of Package 1	1
Number of Units in Package 1	1
Package 1 Height	28.6 cm
Package 1 Width	9.4 cm
Package 1 Length	7.2 cm
Package 1 Weight	180 g
