Picture of discrete output module Modicon Momentum - 8 O solid state
SKU:

170ADO53050

discrete output module Modicon Momentum - 8 O solid state

$2,838.66 INC GST
Available for Shipping : 20-Jan-2026
discrete output module Modicon Momentum - 8 O solid state
Be the first to review this product
Manufacturer: Schneider Electric
Delivery date: 20-Jan-2026
Environmental Disclosure
Circularity Profile
Declaration of conformity
User guide
Product Page Link
Product Data Sheet

Products specifications

Attribute name Attribute value
Main
Protective treatment TC
Short-circuit protection internal fuse, 5 A slow-blow per group
Discrete output number 8
Discrete output voltage 120 V AC
Product or component type discrete output base AC
Current per channel 2 A
Range of product Modicon Momentum automation platform
Group of channels 2 groups of 4 outputs
Discrete output type triac
Complementary
Isolation between channels and bus 1780 V AC for 1 minute
Depth 47.5 mm
Width 125 mm
Output overload protection internal fuse
Local signalling 8 LEDs for channel status
Maximum leakage current 1.9 mA 120 V AC
Net weight 0.32 kg
Discrete output current 8 A per module, 4 A per group
Marking CE
Surge current 5 A for 3 cycles, 15 A for 1 cycle, 10 A for 2 cycles
Current consumption 125 mA at 120 V AC
Response time 1/2 x 1/f (= 0.5 of one line cycle) from state 1 to state 0, 1/2 x 1/f (= 0.5 of one line cycle) from state 0 to state 1
Maximum voltage drop <1.5 V 2 A at state 1
Terminals description PLC n°1 (8)OUT_DIS#8, (7)OUT_DIS#7, (1N)PW, (6)OUT_DIS#6, (5)OUT_DIS#5, TB, (1L+)PW, (3)OUT_DIS#3, (1)OUT_DIS#1, (2)OUT_DIS#2, (4)OUT_DIS#4
[Ue] rated operational voltage 120 V AC
Minimum output current 5 mA
Height 141.5 mm
Power dissipation 6 W typical, 7.5 W maximum
Environment
Operating altitude <= 5000 m
Resistance to electrostatic discharge 8 kV on air conforming to IEC 801-2, 4 kV contact conforming to IEC 801-2
Relative humidity 95-95 % without condensation
Ambient air temperature for storage -40-85 °C
Resistance to electromagnetic fields 10 V/m 80...1000 MHz conforming to IEC 801-3
Ambient air temperature for operation 0-60 °C
Product certifications UL, FM Class 1 Division 2, CSA
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 9.000 cm
Package 1 Width 18.000 cm
Package 1 Length 26.000 cm
Package 1 Weight 531.000 g
Unit Type of Package 2 2
Number of Units in Package 2 6
Package 2 Height 30.000 cm
Package 2 Width 30.000 cm
Package 2 Length 40.000 cm
Package 2 Weight 3.975 kg
