Picture of discrete I/O module Modicon Momentum - 16 I/O relay
SKU:

170ADM85010

discrete I/O module Modicon Momentum - 16 I/O relay

$2,861.43 INC GST
Available for Shipping : 06-Jan-2026
discrete I/O module Modicon Momentum - 16 I/O relay
Be the first to review this product
Manufacturer: Schneider Electric
Delivery date: 06-Jan-2026
Circularity Profile
User guide
Environmental Disclosure
Instruction sheet
Declaration of conformity
Product Page Link
Product Data Sheet
This I/O module is part of the Modicon Momentum range, an offer of controller and IP20 monoblock I/Os for distributed control architecture. It is a discrete relay I/O base for DC. This relay supports one group of 16 inputs and one group of 16 outputs. It serves as solid state switch. The internal communications connector provides automatic communication to any adapter mounted on the base. It is certified FM Class 1 Division 2, CSA, and UL. It weighs 0.41kg. The I/O base provides the foundation for the rest of the Momentum control system. A Momentum I/O base is to be assembled with a communication adapter or a processor adapter. Momentum I/O base has mounting holes for a panel mount and a locking tab for a DIN rail mount. Momentum I/O bases offer simple plug-in terminal strips. Modicon Momentum is a flexible, modular family of fundamental components. Modicon Momentum products are specially designed for material handling, simple machine control, and building automation applications.

Products specifications

Attribute name Attribute value
Main
Protective treatment TC
Discrete input number 16 conforming to IEC 1131-2 Type 3
Discrete input logic positive
Discrete output number 16
Discrete output voltage 48 V DC, 24 V DC, 12 V DC, <= 60 V DC
Product or component type discrete relay I/O base DC
Discrete input voltage 48 V DC, 12 V DC, 24 V DC
Discrete output logic positive
Range of product Modicon Momentum automation platform
Group of channels 1 group of 16 inputs, 1 group of 16 outputs
Discrete output type solid state switch
Complementary
[Us] rated supply voltage 48 V DC, 24 V DC, 12 V DC
Discrete output current 8 A 50 °C per group, 7 A 60 °C per module, 0.5 A per point
Depth 47.5 mm
Width 125 mm
Peak output current 5 A
Voltage state 1 guaranteed > 7.5 V 12 V, > 30 V 48 V, > 11 V 24 V
Maximum leakage current 1 mA at 60 V (output circuit)
Voltage state 0 guaranteed < 5 V 24 V, < 2.5 V 12 V, < 10 V 48 V
Response time 3.3 ms from state 1 to state 0 on input, 2.2 ms from state 0 to state 1 on input, < 0.1 ms from state 1 to state 0 on output, < 0.1 ms from state 0 to state 1 on output
Input voltage limits 10...60 V
Current state 1 guaranteed 2.9 mA 48 V, 2.7 mA 24 V, 2.3 mA 12 V
Current consumption 500 mA at 12 V DC, 125 mA at 48 V DC, 250 mA at 24 V DC
Isolation between channels and bus 707 V DC
Maximum voltage drop <1 V 0.5 A at state 1 output circuit
Fault type overload on output
Isolation between group of I/O channels 707 V DC
Height 141.5 mm
Power dissipation 6.0 + (0.144 x number of input points) + (0.25 x number of output points)
Environment
Operating altitude <= 5000 m
Resistance to electrostatic discharge 8 kV on air conforming to IEC 801-2, 4 kV contact conforming to IEC 801-2
Relative humidity 95-95 % without condensation
Ambient air temperature for storage -40-85 °C
Resistance to electromagnetic fields 10 V/m 80...1000 MHz conforming to IEC 801-3
Ambient air temperature for operation 0-60 °C
Product certifications CSA, UL, FM Class 1 Division 2
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 5.5 cm
Package 1 Width 18.0 cm
Package 1 Length 26.0 cm
Package 1 Weight 380.0 g
Unit Type of Package 2 2
Number of Units in Package 2 8
Package 2 Height 30.0 cm
Package 2 Width 30.0 cm
Package 2 Length 40.0 cm
Package 2 Weight 3.476 kg
