Picture of discrete I/O module Modicon Momentum - 10I / 8O solid state
SKU:

170ADM69051

discrete I/O module Modicon Momentum - 10I / 8O solid state

$2,772.88 INC GST
Available for Shipping : 20-Jan-2026
discrete I/O module Modicon Momentum - 10I / 8O solid state
Be the first to review this product
Manufacturer: Schneider Electric
Delivery date: 20-Jan-2026
Environmental Disclosure
Circularity Profile
Declaration of conformity
User guide
Product Page Link
Product Data Sheet
This I/O module is part of the Modicon Momentum range, an offer of controller and IP20 monoblock I/Os for distributed control architecture. This discrete triac I/O base AC module offers 1 group of 10 inputs and 1 group of 8 outputs with positive discrete input logic. It is a module with discrete input voltage of 120V AC and discrete output voltage ranges from 120V DC to 132V DC. There is an isolation between channels and bus at 1780V AC. Its dimensions are 125mm (width) x 47.5mm (depth) x 141.5mm (height). It weighs 0.22kg. The main application of this module is infrastructures and energy, material handling, simple machine control. This product is certified by CE, CSA and UL. It is suitable for wall mount. Momentum is a flexible, modular family of components that easily snaps together and can be configured for a wide range of distributed I/O and control applications. System with 4 fundamental components that easily snap together in various combinations to form versatile control systems or sub-systems.

Products specifications

Attribute name Attribute value
Main
Protective treatment TC
Discrete input number 10 conforming to IEC 1131-2 Type 2
Discrete input logic positive
Discrete output number 8
Discrete output voltage 120...132 V DC
Product or component type discrete triac I/O base AC
Discrete input voltage 120 V AC
Discrete output logic positive
Range of product Modicon Momentum automation platform
Group of channels 1 group of 8 outputs, 1 group of 10 inputs
Discrete output type triac
Complementary
[Us] rated supply voltage 120 V AC
Discrete output current 30 mA...0.5 A per point, 4 A per module, 2 A per group
Depth 47.5 mm
Width 125 mm
Protection type internal 2 x 2.5 A slow-blow fuses
Input resistance 4 kOhm
Voltage state 1 guaranteed > 74 V
Maximum leakage current 1.3 mA at 120 V (output circuit)
Voltage state 0 guaranteed < 20 V
Net weight 0.22 kg
Response time 1/2 x 1/f from state 1 to state 0 on output, 1/2 x 1/f from state 1 to state 0 on input, 1/2 x 1/f from state 0 to state 1 on output, 1/2 x 1/f from state 0 to state 1 on input
Input voltage limits 74...132 V
Current state 0 guaranteed <= 2.6 mA
Marking CE
Current state 1 guaranteed >= 6 mA
Current consumption 160 mA at 120 V AC
Isolation between channels and bus 1780 V AC
Maximum voltage drop <1.5 V 0.5 A at state 1 output circuit
Terminals description PLC n°1 (2)IN_DIS#2, TB, (1)IN_DIS#1, (7)IN_DIS#7, (6)IN_DIS#6, (N)PW, (L1)PW, (3)IN_DIS#3, (10)IN_DIS#10, (4)IN_DIS#4, (9)IN_DIS#9, (5)IN_DIS#5, (8)IN_DIS#8
Terminals description PLC n°2 TB_1, (5)OUT_DIS#5, (4)OUT_DIS#4, (1)OUT_DIS#1, (7)OUT_DIS#7, (8)OUT_DIS#8, (1L1)PW, (2)OUT_DIS#2, (1N)PW, (6)OUT_DIS#6, (3)OUT_DIS#3
Operating rate 3000 cyc/h 0.5 A inductive
Height 141.5 mm
Power dissipation 6 W, <= 8 W
Network frequency 47...63 Hz
Environment
Operating altitude <= 5000 m
Resistance to electrostatic discharge 8 kV on air conforming to IEC 801-2, 4 kV contact conforming to IEC 801-2
Relative humidity 95-95 % without condensation
Ambient air temperature for storage -40-85 °C
Resistance to electromagnetic fields 10 V/m 80...1000 MHz conforming to IEC 801-3
Ambient air temperature for operation 0-60 °C
Product certifications CSA, UL
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 9.000 cm
Package 1 Width 18.500 cm
Package 1 Length 25.500 cm
Package 1 Weight 484.000 g
Unit Type of Package 2 2
Number of Units in Package 2 6
Package 2 Height 30.000 cm
Package 2 Width 30.000 cm
Package 2 Length 40.000 cm
Package 2 Weight 3.356 kg
