Picture of discrete I/O module Modicon Momentum - 16I / 8O solid state
SKU:

170ADM37010

discrete I/O module Modicon Momentum - 16I / 8O solid state

$2,547.71 INC GST
Available for Shipping : 20-Jan-2026
discrete I/O module Modicon Momentum - 16I / 8O solid state
Be the first to review this product
Manufacturer: Schneider Electric
Delivery date: 20-Jan-2026
Circularity Profile
User guide
Environmental Disclosure
Instruction sheet
Declaration of conformity
Product Page Link
Product Data Sheet
This I/O module is part of the Modicon Momentum range, an offer of controller and IP20 monoblock I/Os for distributed control architecture. It is a discrete solid state I/O base for DC. This solide state I/O base supports four groups of 4 inputs and two groups of 4 outputs. Momentum I/O base supports the whole control system. The internal communications connector provides automatic communication to any adapter mounted on the base. It is a CSA and UL certified product. It weighs 0.22kg. The I/O base provides the foundation for the rest of the Momentum control system. A Momentum I/O base is to be assembled with a communication adapter or a processor adapter. Momentum I/O base has mounting holes for a panel mount and a locking tab for a DIN rail mount. Momentum I/O bases offer simple plug-in terminal strips. Modicon Momentum is a flexible, modular family of fundamental components. Modicon Momentum products are specially designed for material handling, simple machine control, and building automation applications.

Products specifications

Attribute name Attribute value
Main
Protective treatment TC
Discrete input number 16 conforming to IEC 1131-2 Type 1
Discrete input logic positive
Discrete output voltage 24 V DC, <= 30 V DC
Discrete input voltage 24 V DC
Discrete output logic positive
Range of product Modicon Momentum automation platform
Group of channels 2 groups of 4 outputs, 4 groups of 4 inputs
Discrete output type solid state switch
Discrete output number 8
Product or component type discrete solid state I/O base DC
Complementary
Voltage state 0 guaranteed -3...5 V
Input voltage limits - 3...30 V
Marking CE
Isolation between channels and bus 500 V AC
Fault type overload on output, short circuit on output
Height 141.5 mm
[Us] rated supply voltage 24 V DC
Discrete output current 8 A per group, 2 A per point, 16 A per module
Depth 47.5 mm
Width 125 mm
Peak output current 2.8 A
Input resistance 4 kOhm
Voltage state 1 guaranteed 11...30 V
Maximum leakage current 1 mA at 24 V (output circuit)
Net weight 0.22 kg
Response time 3.3 ms from state 1 to state 0 on input, 2.2 ms from state 0 to state 1 on input, < 0.1 ms from state 1 to state 0 on output, < 0.1 ms from state 0 to state 1 on output
Current state 0 guaranteed <= 1.2 mA
Current state 1 guaranteed >= 2.5 mA
Current consumption 250 mA at 24 V DC
Terminals description PLC n°1 (9)IN_DIS#9, (3)IN_DIS#3, (2)IN_DIS#2, (8)IN_DIS#8, (10)IN_DIS#10, (12)IN_DIS#12, TB, (5)IN_DIS#5, (13)IN_DIS#13, (14)IN_DIS#14, (6)IN_DIS#6, (4)IN_DIS#4, (1)IN_DIS#1, (16)IN_DIS#16, (15)IN_DIS#15, (7)IN_DIS#7, (L+)PW_POS, (M-)PW_NEG, (11)IN_DIS#11
Terminals description PLC n°2 TB_1, (2L+)PW_POS, (1L+)PW_POS, (3)OUT_DIS#3, (7)OUT_DIS#7, (8)OUT_DIS#8, (6)OUT_DIS#6, (4)OUT_DIS#4, (2)OUT_DIS#2, (1)OUT_DIS#1, (5)OUT_DIS#5
Power dissipation <= 10 W, 6.5 W
Environment
Resistance to electrostatic discharge 8 kV on air conforming to IEC 801-2, 4 kV contact conforming to IEC 801-2
Relative humidity 95-95 % without condensation
Ambient air temperature for storage -40-85 °C
Resistance to electromagnetic fields 10 V/m 80...1000 MHz conforming to IEC 801-3
Ambient air temperature for operation 0-60 °C
Operating altitude <= 5000 m
Product certifications CSA, UL
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 5.500 cm
Package 1 Width 18.000 cm
Package 1 Length 26.000 cm
Package 1 Weight 394.000 g
Unit Type of Package 2 2
Number of Units in Package 2 10
Package 2 Height 30.000 cm
Package 2 Width 30.000 cm
Package 2 Length 40.000 cm
Package 2 Weight 4.381 kg
