Picture of relay discrete output module Modicon Quantum - 8 O
SKU:

140DRC83000

relay discrete output module Modicon Quantum - 8 O

$2,567.14 INC GST
Availability: Please contact our sales team on 1300 724 622.
relay discrete output module Modicon Quantum - 8 O
Be the first to review this product
Manufacturer: Schneider Electric
User guide
CAD
Declaration of conformity
Instruction sheet
Catalog
Product Page Link
Product Data Sheet

Products specifications

Attribute name Attribute value
Main
Discrete output number 8
Product or component type relay discrete output module
Range of product Modicon Quantum automation platform
Complementary
Isolation between channels and bus 2500 V DC for 1 minute, 1780 Vrms AC for 1 minute
Module format standard
Mechanical durability 10000000 cycles
Local signalling 8 LEDs (green) for input status, 1 LED (red) for external fault detected (F), 1 LED (green) for bus communication is present (Active)
Addressing requirement 0.5 output word
Bus current requirement 560 mA
Contacts type and composition 1 NO/NC
Maximum response time on input open 20 ms at state 1 to state 0, 10 ms at state 0 to state 1
Switching frequency F = 0.5/I²L inductive load, 30 Hz resistive load
Isolation between channels 2500 V DC, 1780 Vrms AC for 1 minute
Net weight 0.3 kg
Surge current 20 A for 10 ms capacitive
Output overvoltage protection internal by varistor, 275 V
Marking CE
Discrete output voltage 5...30 V DC, 30...150 V DC, 20...250 V AC
Contact form Form C
Electrical durability 50000 cycles 500 mA 30...150 V DC resistive, 200000 cycles 5 A 250 V AC resistive, 100000 cycles 5 A 30 V DC resistive, 100000 cycles 300 mA 30...150 V DC resistive, 100000 cycles 30...150 V DC interposing relay, 100000 cycles 100 mA 30...150 V DC L/R = 10 ms
Switching capacity in VA 1250 VA resistive
Maximum load current 5 A 250/30 V AC/DC resistive at 60 °C, 300 mA 30...50 V DC resistive, 3 A 250/30 V AC/DC, 2 A 250/30 V AC/DC tungsten 1/4 hp cos phi = 0.4 , 100 mA 30...50 V DC L/R = 10 ms
Power dissipation 2.75 W + (0.5 x the number of points on)
Environment
Operating altitude <= 5000 m
Resistance to electrostatic discharge 8 kV on air conforming to IEC 801-2, 4 kV contact conforming to IEC 801-2
Relative humidity 95-95 % without condensation
Ambient air temperature for storage -40-85 °C
Standards CSA C22.2 No 142, UL 508
Resistance to electromagnetic fields 10 V/m 80-2000 MHz conforming to IEC 801-3
Ambient air temperature for operation 0-60 °C
Product certifications RINA, DNV, ABS, FM Class 1 Division 2, RMRS, GL, GOST, C-Tick
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 16.3 cm
Package 1 Width 4.5 cm
Package 1 Length 31.2 cm
Package 1 Weight 475.0 g
