SKU:

140CPS41400

power supply module Modicon Quantum - 48..60 V DC - summable

$7,495.49 INC GST

Qty:

Availability: Please contact our sales team on 1300 724 622.

power supply module Modicon Quantum - 48..60 V DC - summable

Manufacturer: Schneider Electric

Declaration of conformity

User guide

Instruction sheet

Catalog

CAD

Product Page Link

Product Data Sheet

Attribute name	Attribute value
Main
Power supply type	summable
Product or component type	power supply module
Range of product	Modicon Quantum automation platform
Complementary
Input voltage	48...60 V (48...60 V) DC
Inrush current	14 A 40 V
Module format	standard
Output overload protection	internal
Local signalling	1 LED (green) for power (PWR OK)
Net weight	0.65 kg
Power supply output current	8-8 A summable
Alarm output	1 NC 6 A 220 V power supply fault
Input current	3800 mA
Associated fuse rating	2 A, time-lag
Output overvoltage protection	internal
Marking	CE
Maximum input power interruption	13 ms 48 V
Output voltage	5.1 V DC
Power dissipation	15.6 W
Environment
Operating altitude	<= 5000 m
Resistance to electrostatic discharge	8 kV on air conforming to IEC 801-2, 4 kV contact conforming to IEC 801-2
Relative humidity	95-95 % without condensation
Ambient air temperature for storage	-40-85 °C
Standards	CSA C22.2 No 142, UL 508
Resistance to electromagnetic fields	10 V/m 80-2000 MHz conforming to IEC 801-3
Ambient air temperature for operation	0-60 °C
Product certifications	cUL
Packing Units
Unit Type of Package 1	1
Number of Units in Package 1	1
Package 1 Height	16.3 cm
Package 1 Width	4.5 cm
Package 1 Length	31.2 cm
Package 1 Weight	815 g
