Picture of discrete output module Modicon Quantum - 16 O - 10..60 V DC
SKU:

140DDO84300

discrete output module Modicon Quantum - 16 O - 10..60 V DC

$3,195.88 INC GST
Available for Shipping : 26-Jan-2026
discrete output module Modicon Quantum - 16 O - 10..60 V DC
Be the first to review this product
Manufacturer: Schneider Electric
Delivery date: 26-Jan-2026
Instruction sheet
CAD
Declaration of conformity
Catalog
User guide
Product Page Link
Product Data Sheet

Products specifications

Attribute name Attribute value
Main
Discrete output number 16
Product or component type dc discrete output module
Range of product Modicon Quantum automation platform
Complementary
Isolation between channels and bus 2500 Vrms DC for 1 minute
Module format standard
Protection type internal output protection by 8 A fuse per group
Local signalling 16 LEDs (green) for input status, 1 LED (red) for external fault detected (F), 1 LED (green) for bus communication is present (Active)
Addressing requirement 1 output word
Output voltage limits 10.2...72 V
Absolute maximum output 72 V permanent
Load inductance inductance(H) = 0.5/((current(A))² x (switching frequency(Hz)))
Maximum leakage current 1 mA 60 V
Net weight 0.45 kg
Associated fuse rating 8 A per group, 2 A each point
Surge current 7.5 A for 50 s
Marking CE
Discrete output voltage 10...60 V DC
Isolation between group 700 Vrms DC for 1 minute
Maximum voltage drop <1 V 2 A
Response time <= 1 ms at state 1 to state 0, <= 1 ms at state 0 to state 1
Bus current requirement 160 mA
Discrete output logic positive logic (source)
Group of channels 2 groups of 8
Maximum load current 6 A per group, 12 A per module
Power dissipation 1 W + (1 V x total module load current)
Environment
Operating altitude <= 5000 m
Resistance to electrostatic discharge 8 kV on air conforming to IEC 801-2, 4 kV contact conforming to IEC 801-2
Relative humidity 95-95 % without condensation
Ambient air temperature for storage -40-85 °C
Standards UL 508, CSA C22.2 No 142
Resistance to electromagnetic fields 10 V/m 80-2000 MHz conforming to IEC 801-3
Ambient air temperature for operation 0-60 °C
Product certifications C-Tick, FM Class 1 Division 2, RMRS, GOST
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 4.73 cm
Package 1 Width 16.33 cm
Package 1 Length 30.91 cm
Package 1 Weight 452.6 g
