Picture of discrete output module Modicon Quantum - 96 O - 24 V DC
SKU:

140DDO36400

discrete output module Modicon Quantum - 96 O - 24 V DC

$6,966.96 INC GST
Availability: Please contact our sales team on 1300 724 622.
discrete output module Modicon Quantum - 96 O - 24 V DC
Be the first to review this product
Manufacturer: Schneider Electric
CAD
Declaration of conformity
Catalog
User guide
Instruction sheet
Product Page Link
Product Data Sheet

Products specifications

Attribute name Attribute value
Main
Discrete output number 96
Product or component type dc discrete output module
Range of product Modicon Quantum automation platform
Complementary
Isolation between channels and bus 500 Vrms DC for 1 minute
Module format standard
Output overload protection with
Local signalling 96 LEDs (green) for input status, 1 LED (red) for external fault detected (F), 1 LED (green) for bus communication is present (Active)
Fault indication fault reporting, loss of field power, fault point, fault sensing
Addressing requirement 6 output words
Output voltage limits 19.2...30 V
Short-circuit protection with
Load inductance inductance(H) = 0.5/((current(A))² x (switching frequency(Hz))) 0.5...4 Hz
Maximum leakage current 1 mA 24 V
Net weight 0.45 kg
Surge current 2 A
Marking CE
Discrete output voltage 24 V DC
Maximum voltage drop <0.4 V 0.5 A
Response time <= 0.1 ms at state 1 to state 0, <= 0.1 ms at state 0 to state 1
Bus current requirement 250 mA
Discrete output logic negative logic (sink)
Group of channels 6 groups of 16
Maximum load current <= 3.2 A each group, <= 19.2 A per module, <= 0.5 A each point
Power dissipation 7 W
Environment
Operating altitude <= 5000 m
Resistance to electrostatic discharge 8 kV on air conforming to IEC 801-2, 4 kV contact conforming to IEC 801-2
Relative humidity 95-95 % without condensation
Ambient air temperature for storage -40-85 °C
Standards UL 508, CSA C22.2 No 142
Resistance to electromagnetic fields 10 V/m 80-2000 MHz conforming to IEC 801-3
Ambient air temperature for operation 0-60 °C
Product certifications FM Class 1 Division 2, GOST, RMRS, C-Tick
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 16.3 cm
Package 1 Width 4.5 cm
Package 1 Length 31.2 cm
Package 1 Weight 545.0 g
Unit Type of Package 2 2
Number of Units in Package 2 7
Package 2 Height 30.0 cm
Package 2 Width 30.0 cm
Package 2 Length 40.0 cm
Package 2 Weight 4.33 kg
