Picture of discrete I/O module Modicon Quantum - 4 I - 125 V DC - 4 O solid state
SKU:

140DDM69000

discrete I/O module Modicon Quantum - 4 I - 125 V DC - 4 O solid state

$5,248.68 INC GST
Available for Shipping : 26-Jan-2026
discrete I/O module Modicon Quantum - 4 I - 125 V DC - 4 O solid state
Be the first to review this product
Manufacturer: Schneider Electric
Delivery date: 26-Jan-2026
Declaration of conformity
User guide
Catalog
Instruction sheet
CAD
Product Page Link
Product Data Sheet

Products specifications

Attribute name Attribute value
Main
Discrete I/O number 8
Product or component type mixed discrete I/O module
Range of product Modicon Quantum automation platform
Complementary
Discrete input number 4 1 group of 8
Protection type on input by resistor limited, on output by transient voltage suppression, internal output protection by 5 A fuse per group
Local signalling 4 LEDs (red) for fault detected on the input point, 4 LEDs (green) for output is turned on, 2 LEDs (red) for fault detected on the output point, 1 LED (red) for no voltage in output and input (F), 1 LED (green) for bus communication is present (Active)
Fault indication overcurrent on output
Addressing requirement 1 output word, 1 input word
Bus current requirement 350 mA
Discrete input logic sink
Absolute maximum output 30 A during 500 ms per point
Discrete output voltage 24...125 V
Voltage state 1 guaranteed 88...156.2 V
Output voltage limits 19.2...156.2 V DC typical
Maximum leakage current 1.2 mA 150 V DC
Voltage state 0 guaranteed 0...36 V
Net weight 0.3 kg
Associated fuse rating 5 A
Input voltage limits 156.2 V including ripple
Response time 0.5 or 1.5 ms depending on the filter at at state 1 to state 0, 0.5 or 1.5 ms depending on the filter at at state 0 to state 1
Current state 0 guaranteed <= 1.2 mA
Marking CE
Current state 1 guaranteed >= 2 mA
Network frequency limits 47-63 Hz
Isolation between channels 1780 Vrms for 1 minute
Maximum load capacitance 0.6 µF 24 V DC, 0.1 µF 150 V DC
Discrete output number 4 1 group of 4
Isolation between group and bus 2500 Vrms for 1 minute
Maximum voltage drop <0.75 V 4 A
Discrete input voltage 125 V DC
Discrete output logic source or sink
Isolation between group of I/O channels 1780 Vrms for 1 minute
Maximum load current <= 4 A per point, <= 16 A per module
Discrete output type solid state, isolated
Power dissipation 0.4 W + (1 x input point on) + (0.75 total output load current)
Environment
Operating altitude <= 5000 m
Resistance to electrostatic discharge 8 kV on air conforming to IEC 801-2, 4 kV contact conforming to IEC 801-2
Relative humidity 95-95 % without condensation
Ambient air temperature for storage -40-85 °C
Standards FM Class 1 Division 2, CSA C22.2 No 142, UL 508
Resistance to electromagnetic fields 10 V/m 80-1000 MHz conforming to IEC 801-3
Ambient air temperature for operation 0-60 °C
Product certifications cUL
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 16.3 cm
Package 1 Width 4.5 cm
Package 1 Length 31.2 cm
Package 1 Weight 655.0 g
