Picture of discrete input module Modicon Quantum - 32 I 24 V DC
SKU:

140DDI35300

discrete input module Modicon Quantum - 32 I 24 V DC

$3,500.64 INC GST
Availability: Please contact our sales team on 1300 724 622.
discrete input module Modicon Quantum - 32 I 24 V DC
Be the first to review this product
Manufacturer: Schneider Electric
CAD
Declaration of conformity
Catalog
Instruction sheet
User guide
Product Page Link
Product Data Sheet

Products specifications

Attribute name Attribute value
Main
Discrete input number 32
Product or component type low voltage dc discrete input modules
Range of product Modicon Quantum automation platform
Complementary
Maximum leakage current 200 mA at Us = 5.5 V and Uin = 4 V
Module format standard
Protection type input protection by resistor limited
Absolute maximum input 56 V during 1.3 ms decaying pulse, 30 V continuous
Input impedance 2500 Ohm
Local signalling 32 LEDs (green) for input status, 1 LED (red) for external fault detected (F), 1 LED (green) for bus communication is present (Active)
Addressing requirement 2 input words
Bus current requirement 330 mA
Voltage state 1 guaranteed 15...30 V DC
Voltage state 0 guaranteed -3...5 V DC
Net weight 0.3 kg
Isolation between group 500 Vrms for 1 minute
Input voltage limits 19.2...30 V
Current state 0 guaranteed <= 0.5 mA
Current state 1 guaranteed >= 2 mA at Us = 5.5 V and Uin = 0 V
Marking CE
Response time <= 1 ms from state 1 to state 0, <= 1 ms from state 0 to state 1
Isolation between group and bus 1780 Vrms for 1 minute
Discrete input voltage 24 V DC
Group of channels 4
Power dissipation 1.7 W + (0.36 x number of points on)
Logic input positive (sink)
Environment
Operating altitude <= 5000 m
Resistance to electrostatic discharge 8 kV on air conforming to IEC 801-2, 4 kV contact conforming to IEC 801-2
Relative humidity 95-95 % without condensation
Ambient air temperature for storage -40-85 °C
Standards UL 508, CSA C22.2 No 142
Resistance to electromagnetic fields 10 V/m 80-2000 MHz conforming to IEC 801-3
Ambient air temperature for operation 0-60 °C
Product certifications ABS, GOST, BV, RMRS, RINA, DNV, C-Tick
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 4.65 cm
Package 1 Width 16.45 cm
Package 1 Length 30.97 cm
Package 1 Weight 409.2 g
