Picture of Unity processor Modicon Quantum - 1056 kB - 66 MHz - coated
SKU:

140CPU43412UC

Unity processor Modicon Quantum - 1056 kB - 66 MHz - coated

$55,156.30 INC GST
Availability: Please contact our sales team on 1300 724 622.
Unity processor Modicon Quantum - 1056 kB - 66 MHz - coated
Be the first to review this product
Manufacturer: Schneider Electric
Instruction sheet
Declaration of conformity
Catalog
Product Page Link
Product Data Sheet

Products specifications

Attribute name Attribute value
Main
Range of product Modicon Quantum automation platform
Product or component type Unity processor
Complementary
Memory description internal RAM 1056 kB
Analogue I/O number unlimited (26 slots max) - local, 1984 inputs,1984 outputs - S908 remote I/O, 500 inputs, 500 outputs - distributed - per network Modbus Plus
Number of instructions per ms 2.49 Kinst/ms 65 % Boolean and 35 % numerical, 1.86 Kinst/ms 100 % Boolean
Application structure no auxiliary task - , 64 interrupt tasks - , 64 I/O interrupt tasks - , 16 timer interrupt tasks - , 1 periodic fast task - , 1 cyclic/periodic master task -
Bus current requirement 1800 mA
Application specific I/O serial link, accurate time stamping, counter, high-speed interrupt inputs
Number of slots 2, 10, 4, 6, 16
Number of remote I/O station 0 - 0 rack(s) per ethernet remote I/O, 31 - 2 rack(s) per S908 remote I/O
Number of optional modules 6 (Ethernet, Modbus, Modbus Plus, Profibus DP, Sy/Max)
Clock frequency 66 MHz
Checks process control
Maximum number of connections 6 Profibus DP - local, 6 Modbus Plus - local, 6 Ethernet TCP/IP - local, 4 AS-Interface - remote, 2 Modbus (RS232/485 Modbus/ASCII), 2 AS-Interface - distributed
Switch function key switch memory start/stop memory protection, slide switch communication port : ASCII/RTU/Memory
Local signalling 1 LED (red) for communications error on the Modbus Plus port (ERROR A), 1 LED (red) for battery needs replacing or is not present (BAT LOW), 1 LED (orange) for write-protected memory (memory port), 1 LED (green) for CPU has passed the power-up diagnostic tests (READY), 1 LED (green) for CPU has been started and is solving logic (RUN), 1 LED (green) for communications are active on the Modbus port (Modbus), 1 LED (green) for communications are active on the Modbus Plus port (Modbus Plus)
Integrated connection type 2 Modbus with , 1 Modbus Plus with
Execution time per instruction 0.12...0.585 µs on word, 0.12...0.585 µs Boolean, 0.1...0.27 µs on fixed-point arithmetic, 0.1...0.27 µs floating points
Discrete I/O number unlimited (26 slots max) - local, 8000 inputs, 8000 outputs - distributed - per network Modbus Plus, 31744 inputs, 31744 outputs - remote
System overhead 1 ms for master task, 0.2 ms for fast task
Number of racks 2 - local rack(s)
Number of distributed I/O station 63 station(s) - 1 rack(s) - 3 Modbus Plus network(s)
Electrical connection 2 female connectors, connector type: SUB-D 9 for connecting to the Modbus bus, 1 female connector, connector type: SUB-D 9 for connecting to the Modbus Plus network
Environment
Protective treatment conformal coating Humiseal 1A33
Standards HazLoc
Product certifications GOST, Misc (Marine), UL, CE, CSA
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 5.0 cm
Package 1 Width 16.5 cm
Package 1 Length 31.5 cm
Package 1 Weight 635.0 g
