Picture of Light block, Harmony XB4, Harmony XB5, white, for head 22mm integral LED, pins for printed circuit board, 24V
SKU:

ZBVB17

Light block, Harmony XB4, Harmony XB5, white, for head 22mm integral LED, pins for printed circuit board, 24V

Old price: $63.14 INC GST
$49.25 INC GST
Available for Shipping : 15-Dec-2025
Light block, Harmony XB4, Harmony XB5, white, for head 22mm integral LED, pins for printed circuit board, 24V
Be the first to review this product
Manufacturer: Schneider Electric
Delivery date: 15-Dec-2025
Declaration of conformity
Environmental Disclosure
Circularity Profile
CAD
Catalog
Instruction sheet
Product Page Link
Product Data Sheet
This Harmony ZB, white light block operates with an integral LED. It is supplied with 24V AC/DC. It is compatible with Harmony XB4 and XB5. This light block allows fast and easy replacement and configuration of your signaling units. It is easily installed and replaced on compatible illuminated push-button or selector switch units via clip together assembly and connected with simple screw-clamp connections. It enables visual distinction of signaling units via illumination by integral LED. It protects operators from unexpected contact with live circuits thanks to its IP20 protection index. Its wide range of operating temperatures from -40°C to 70°C allows versatility in usage of product.

Products specifications

Attribute name Attribute value
Main
Device short name ZBV
Light source colour white
Sale per indivisible quantity 5
Light block supply direct
Range of product Harmony XB5, Harmony XB4
Bulb base integral LED
[Us] rated supply voltage 24 V AC/DC at 50/60 Hz
Signalling type steady
Connections - terminals pins for printed circuit board
Product or component type light block
Light source protected LED
Complementary
Compatibility code ZBV
Supply voltage limits 21.6-26.4 V AC, 19.2-30 V DC
Surge withstand 1 kV conforming to IEC 61000-4-5
Electrical composition code PF1, P2, P1, MF1, M10, M6, M5, M4, M3, M2, M1
Service life 100000 h at rated voltage and 25 °C
Current consumption 18 mA
Net weight 0.004 kg
Mounting of block front mounting
Environment
Resistance to fast transients 2 kV conforming to IEC 61000-4-4
Protective treatment TH
Resistance to electrostatic discharge 8 kV in free air (in insulating parts) conforming to IEC 61000-4-2, 6 kV on contact (on metal parts) conforming to IEC 61000-4-2
Ambient air temperature for storage -40-70 °C
IP degree of protection IP20 conforming to IEC 60529
Resistance to electromagnetic fields 10 V/m conforming to IEC 61000-4-3
Ambient air temperature for operation -40-70 °C
[Us] rated supply voltage 24 V
Electromagnetic emission class B conforming to IEC 55011
Standards JIS C8201-1, EN/IEC 60947-5-1, JIS C8201-5-1, EN/IEC 60947-5-4, UL 508, EN/IEC 60947-5-5, EN/IEC 60947-1, CSA C22.2 No 14
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 0.500 cm
Package 1 Width 2.000 cm
Package 1 Length 5.000 cm
Package 1 Weight 2.000 g
Unit Type of Package 2 2
Number of Units in Package 2 5
Package 2 Height 2.300 cm
Package 2 Width 3.400 cm
Package 2 Length 6.500 cm
Package 2 Weight 17.000 g
Unit Type of Package 3 3
Number of Units in Package 3 200
Package 3 Height 15.000 cm
Package 3 Width 15.000 cm
Package 3 Length 40.000 cm
Package 3 Weight 6.939 kg
