Picture of Preventa safety remote mixed I/O module - 16 I not isolated - 16 O not isolated
SKU:

XPSMF3DIO16801

Preventa safety remote mixed I/O module - 16 I not isolated - 16 O not isolated

$10,861.52 INC GST
Available for Shipping : 01-Feb-2026
Preventa safety remote mixed I/O module - 16 I not isolated - 16 O not isolated
Be the first to review this product
Manufacturer: Telemecanique
Delivery date: 01-Feb-2026
User guide
Catalog
Product Page Link
Product Data Sheet

Products specifications

Attribute name Attribute value
Main
Function of module monitoring short-circuit and line break for line control outputs, monitoring safety dialogue for discrete output, monitoring safety dialogue for discrete input, monitoring safety detection for discrete input, monitoring safety actuators for discrete output, monitoring safety actuators for discrete input
Safety use category SIL 3 conforming to EN/IEC 61508, performance level e conforming to EN/ISO 13849-1, category 4 maximum conforming to EN 954-1
Discrete input number 16 not isolated discrete input(s)
Safety module application extension of I/O capacity
Safety module name XPSMF3
Structure type 10BASE-T/100BASE-TX
Supply SELV or PELV conforming to EN/IEC 60950
Product or component type Preventa safety remote mixed I/O module
Discrete output number 16 , not isolated
Number of outputs 2 not isolated for line control outputs
Range of product Preventa Safety automation
[Us] rated supply voltage 24 V DC - 15...20 %
Complementary
Inductive load 500 mH for discrete output
Minimum load 2 mA per channel
Discrete output current <= 9 A (all channels), 2 A at 40 °C (channels 1 to 3, 5 to 7, 4 and 8), 1 A at 60 °C (channels 1 to 3, 5 to 7, 4 and 8), > 10 mA at 60 °C (channels 1 to 3, 5 to 7, 4 and 8)
Depth 86.5 mm
Maximum tungsten load <25 W for discrete output
Width 205 mm
Switching voltage 7.5 V for discrete input
Input protection type protected against short-circuit
Maximum line resistance 5 kOhm for discrete output
Switching time 250 µs
Response time depending on size of application
Current state 0 guaranteed 1...1.5 mA (discrete input)
Voltage state 1 guaranteed 15...< 30 V for discrete input
Nominal output current 60 mA for line control outputs
Maximum leakage current 1 mA, at 2 V at state 0 for discrete output
Communication port protocol safe Ethernet with 2 RJ45 port(s), transmission rate: 100 Mbps, 10 Mbps, medium: dual twisted pair cable, category 5D or better
Discrete output voltage 24 V DC
Voltage state 0 guaranteed <= 5 V for discrete input
Net weight 1.3 kg
Associated fuse rating 16 A, slow-blow
Output voltage tolerance +/- 3 %
Current state 1 guaranteed <= 2 mA (discrete input)
Discrete input current 40 mA
Current consumption 14 A at 24 V DC on power supply
Exchange mode half duplex, full duplex, autonegotiation
Mounting support 35 mm symmetrical DIN rail
Discrete input voltage 20 V
Height 109 mm
Output voltage 20 V line control outputs
Number of terminal blocks 4 for discrete input, 3 for discrete output, 1 for power supply, 1 for line control outputs
Environment
Ambient air temperature for storage -40-85 °C
IP degree of protection IP20
Ambient air temperature for operation 0-60 °C
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 17.0 cm
Package 1 Width 19.5 cm
Package 1 Length 30.0 cm
Package 1 Weight 1.689 kg
