Picture of ConneXium Extended Managed Switch - 8 ports for copper - Coated
SKU:

TCSESM083F23F1C

ConneXium Extended Managed Switch - 8 ports for copper - Coated

$6,438.85 INC GST
Availability: Please contact our sales team on 1300 724 622.
ConneXium Extended Managed Switch - 8 ports for copper - Coated
Be the first to review this product
Manufacturer: Schneider Electric
Declaration of conformity
User guide
Product Page Link
Product Data Sheet

Products specifications

Attribute name Attribute value
Main
Concept Transparent Ready
Cybersecurity port hardening
Product specific application for severe environments
Communication port protocol MRP (Media Redundancy Protocol), SNTP, Telnet, LLDP, RS232, SNMP, HTTPS, HTTP, SSH, Ethernet TCP/IP
Product or component type Ethernet TCP/IP managed switch
Port Ethernet 10/100BASE-TX - 8 port(s) copper cable
Range of product ConneXium
Maximum number of switches in cascade unlimited
Complementary
Depth 115 mm
Width 120 mm
Diagnostics run time self test, signal contact
Local signalling Device status, 1 LED per channel (green/yellow) for channel diagnostic, 1 LED (yellow) for signal contact 2, 1 LED (yellow) for signal contact 1, 1 LED (red) for stand-by, 1 dual colour LED (green/yellow) for ring manager, 1 LED (red) for fault, 1 dual colour LED (green/yellow) for P1 P2 power supplies
Supply voltage limits 18-60 V DC SELV
Ethernet cabling system TF switches
Ethernet service SNMP-Traps and SYSLOG, IGMP Snooping, data stream control, multicast filtering, VLAN, configuration via web server
Function available Trap log, report, system information, alarms (Traps)
Maximum number of switches in a ring 50
Electrical connection 2 removable connectors 2 ways power supply
Net weight 1 kg
Redundancy redundant network coupling, RSTP, HiPER ring
Alarm output 2 voltfree contact 2 A
Marking ATEX, RCM, UL, CE
Communication service address conflict detection, port mirroring, port monitoring, Quality of Service (QoS), TFTP
Power consumption in W 10 W
Mounting support 35 mm symmetrical DIN rail
Transmission support medium twisted shielded pairs cable CAT 5E for copper cable
Integrated connection type shielded RJ45 copper cable
Alarm function external memory removed, temperature threshold, data link status, power supply fault
Height 137 mm
[Us] rated supply voltage 24...48 V
Maximum cable distance between devices 100 m copper cable
Environment
IP degree of protection IP30
Protective treatment conformal coating
Relative humidity 10-95 % non-condensing
Directives 2014/30/EU - electromagnetic compatibility, 2014/35/EU - low voltage directive
Product certifications BV, GL, LR, ATEX, RCM, UL, CE
Standards UL 1604 Class 1 Division 2, CSA C22.2 No 213 Class I Division 2, IEC 61850-3, EN/IEC 61131, UL 508
Ambient air temperature for operation -40-85 °C
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 30.000 cm
Package 1 Width 30.000 cm
Package 1 Length 40.000 cm
Package 1 Weight 2.355 kg
