Picture of 19w Display module, PS6000, Full HD, 16M colors, PCAP Multi Touch (2 points) with optimized noise filter
Picture of 19w Display module, PS6000, Full HD, 16M colors, PCAP Multi Touch (2 points) with optimized noise filter
Picture of 19w Display module, PS6000, Full HD, 16M colors, PCAP Multi Touch (2 points) with optimized noise filter
Picture of 19w Display module, PS6000, Full HD, 16M colors, PCAP Multi Touch (2 points) with optimized noise filter
Picture of 19w Display module, PS6000, Full HD, 16M colors, PCAP Multi Touch (2 points) with optimized noise filter
Picture of 19w Display module, PS6000, Full HD, 16M colors, PCAP Multi Touch (2 points) with optimized noise filter
SKU:

PFXDM6800WC

19w Display module, PS6000, Full HD, 16M colors, PCAP Multi Touch (2 points) with optimized noise filter

Old price: $3,795.00 INC GST
$3,605.25 INC GST
Available for Shipping : 05-Feb-2026
19w Display module, PS6000, Full HD, 16M colors, PCAP Multi Touch (2 points) with optimized noise filter
Be the first to review this product
Manufacturer: ProFace
Delivery date: 05-Feb-2026
User guide
Circularity Profile
Declaration of conformity
Instruction sheet
Environmental Disclosure
Product Page Link
Product Data Sheet
This industrial display belongs to the Pro-face's HMI PS6000 range. This 2 point multi-touch resistive PFXDM6 display has a plastic overlay surface design with backlight service life of 50,000 hours. This is a 18.5 inch wide screen of 16 million colors and 1920 × 1080 pixel resolution (FHD). Three touch mode configurations are available namely Standard mode, Glove mode, and Water detection mode. The modularity of the iPC display facilitates fast deliveries, multiple choices, easier mounting, and optimum ergonomics. The front panel when properly installed in an enclosure provides IP66F, IP67F, Type 1, Type 4X (NEMA indoor use only), and Type 13 degree of protection. The power consumption when this DM6 display is paired with PS6000 Advanced Modular Box is 170VAMax. (AC model) and 150WMax. (DC model), with P6 Standard Modular Box is 92VAMax. (AC model) and 82WMax. (DC model). Its dimensions are 463.6mm (width) x 293.6mm (height) x 32mm (depth) and weighs 4.90Kg. PS6000 industiral PCs caters to the complex machine, line monitor and processes at Edge Control and Apps Analytics level. It complies with CE, RCM, UL 61010-2-201 and CSA C22.2 No. 61010-2-201 for both AC and DC models. They are configurable noise-resistive touch drivers with default standard mode, glove mode, and water detection mode. This display when combined with any of the PS6000 Boxes makes a Panel PC. It can be mounted on front enclosure or VESA 100 × 100 mount on the rear of Box PC. The stylish wide PS6000 displays provide high visibility during operation featuring glass-top capacitive multi-touch panel with narrow frame and thin design. The PS6000 online Configurator with enlarged line-up offers many possibilities

Products specifications

Attribute name Attribute value
Main
Range of product PS6000
Terminal type touchscreen display
Product or component type touch panel screen
Inrush current 30 A
Power consumption in W 82 W (maximum) with standard box, 64 W (typical) with standard box, 150 W (maximum) with advanced box, 85 W (typical) with advanced box
Complementary
Device mounting direct mounting VESA, panel mounting
Display colour 16 million colours
Display resolution 1920 x 1080 pixels full HD
Display size 18.5 inch
Touch panel multi-touch projected capactive technology (PCT) with optimized noise filter
Display type colour TFT LCD, LED not replaceable
Type of cooling natural
Cut-out dimensions 449.5 (+ 1/- 0) x 279.5 (+ 1/- 0) mm
Function available water detection mode, glove mode, standard mode
Backlight lifespan 50000 hours at 25 °C
Depth 32 mm enclosure:
Height 293.6 mm
Aspect ratio 16:9
Width 463.6 mm
Type of installation indoor installation
Net weight 4.9 kg
Pixel resolution 1920 x 1080
Environment
Relative humidity 10-90 % without condensation
Ambient air temperature for storage -20-60 °C
Pollution degree 2
IP degree of protection Type 13, Type 12, Type 4X, Type 1, IP67f, IP66f
Electromagnetic compatibility electrical fast transient/burst immunity test - test level: 1 kV (signal ports) conforming to IEC 61000-4-4, electrical fast transient/burst immunity test - test level: 2 kV (power ports) conforming to IEC 61000-4-4, electrostatic discharge immunity test - test level: 8 kV (air discharge) conforming to IEC 61000-4-2 level 3, electrostatic discharge immunity test - test level: 6 kV (contact discharge) conforming to IEC 61000-4-2 level 3
Product certifications IECEx zone 22 (DC model, front USB cover must be locked with screw), IECEx zone 2 (DC model, front USB cover must be locked with screw), cULus Class 1 Division 2 (without DIO option), ATEX zone 22 dust (DC model, front USB cover must be locked with screw), ATEX zone 2 (DC model, front USB cover must be locked with screw), DNV (DC model without HDD/fan/ EtherCAT card/22" wide display with expansion slot), UKCA, EAC, KC, RCM
Standards CSA C22.2 No 61010-2-201, UL 61010-2-201,  FCC part 15, CE
Ambient air temperature for operation 0-50 °C
Operating altitude 2000 m
Vibration resistance 1 gn X, Y, Z directions for 10 cycles (approx. 100 min) conforming to IEC 61131-2, 1 gn (f = 9-150 Hz) fixed amplitude conforming to IEC 61131-2, 1 gn (f = 5-9 Hz) single amplitude conforming to IEC 61131-2
Environmental characteristic corrosive gas free, dust resistant 0.1 mg/m3 (non-conductive)
Shock resistance 147 m/s² 3 shocks in each direction X, Y and Z, 147 m/s² conforming to IEC 61131-2
Storage Relative Humidity 10-90 % without condensation
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 46.0 cm
Package 1 Width 15.0 cm
Package 1 Length 55.0 cm
Package 1 Weight 5.9 kg
Unit Type of Package 2 2
Number of Units in Package 2 22
Package 2 Height 150.0 cm
Package 2 Width 80.0 cm
Package 2 Length 120.0 cm
Package 2 Weight 139.8 kg
