Picture of Multi9 - undervoltage release - MN - 48 V AC - 48 V DC
SKU:

M9A26961

Multi9 - undervoltage release - MN - 48 V AC - 48 V DC

Old price: $245.30 INC GST
$144.95 INC GST
Available for Shipping : 07-Jan-2026
Multi9 - undervoltage release - MN - 48 V AC - 48 V DC
Be the first to review this product
Manufacturer: Schneider Electric
Delivery date: 07-Jan-2026
Circularity Profile
Brochure
Declaration of conformity
Environmental Disclosure
Catalog
Product Page Link
Product Data Sheet
This Multi9 MN electrical auxiliary is an undervoltage release. It is dedicated to Multi9 GFP, C60BP, C60SP, C60BPR. The width in 9mm pitches is 2. The Uc control circuit voltage is 48VAC or 48VDC. It can be mounted on a DIN rail for modular installation. The operating temperature is -25°C to 50°C. The storage temperature is -40°C to 85°C. This product complies with EN/IEC 60947-1 standard.

Products specifications

Attribute name Attribute value
Main
Device short name MN
Control type standard
Range Multi9
Product or component type undervoltage release
9 mm pitches 2
Range of product GFP, C60BPR, C60SP, C60BP
[Uc] control circuit voltage 48 V DC, 48 V AC 50/60 Hz
Complementary
Tightening torque 1-1 N.m bottom
Depth 68 mm
Width 18 mm
Local signalling action indicator
Mounting mode fixed
Connections - terminals clamp terminal (bottom) - 2 cable(s) 1.5-1.5 mm² (AWG 16) - rigid, clamp terminal (bottom) - 1 cable(s) 2.5-2.5 mm² (AWG 14) - rigid
Wire stripping length 9 mm for bottom connection
Net weight 0.066 kg
Comb busbar and distribution block compatibility top: YES
Range compatibility Multi 9 Multi9 C60H-DC C60H-DC, Multi 9 Multi9 GFP GFP, Multi 9 Multi9 C60 C60SP, Multi 9 Multi9 C60 C60BPR, Multi 9 Multi9 C60 C60BP
Mounting support DIN rail
Height 82.5 mm
Environment
Ambient air temperature for storage -40-85 °C
Pollution degree 3
Standards GB/T 14048.5, C22.2 No. 5, UL 1077, UL 489, EN 60947-2, EN/IEC 60947-5-1, EN/IEC 60947-1
Ambient air temperature for operation -25-50 °C
Product certifications UR, UL, PCT
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 2.900 cm
Package 1 Width 8.000 cm
Package 1 Length 9.400 cm
Package 1 Weight 73.000 g
Unit Type of Package 2 2
Number of Units in Package 2 8
Package 2 Height 8.700 cm
Package 2 Width 10.000 cm
Package 2 Length 26.500 cm
Package 2 Weight 648.000 g
Unit Type of Package 3 3
Number of Units in Package 3 72
Package 3 Height 30.000 cm
Package 3 Width 30.000 cm
Package 3 Length 40.000 cm
Package 3 Weight 6.313 kg
