Picture of Profile busbar, Linergy LGYE, 1600A, for a vertical installation, 32.5x42.5mm, L1670mm
SKU:

LVS04506

Profile busbar, Linergy LGYE, 1600A, for a vertical installation, 32.5x42.5mm, L1670mm

$380.82 INC GST
Available for Shipping : 12-Jan-2026
Profile busbar, Linergy LGYE, 1600A, for a vertical installation, 32.5x42.5mm, L1670mm
  • Linergy LGYE Busbar Profiles
  • Busbar Profiles for vertical installation
  • Number of profiles per phase single/double run
  • with busbar Profile length of L1670mm
  • Linergy Evolution's unique profile, provides performance that is backed by regular testing up to 4000A
  • Devices can be powered anywhere within the panel
Be the first to review this product
Manufacturer: Schneider Electric
Delivery date: 12-Jan-2026
User guide
Instruction sheet
Catalog
Environmental Disclosure
Product Page Link
Product Data Sheet

Products specifications

Attribute name Attribute value
Main
Quantity per set set of 1
Busbar description Linergy
Range Linergy
Product name Linergy LGY
Product or component type profile busbar
Range compatibility PrismaSeT PrismaSeT P enclosure
Range of product Linergy
Complementary
[Icw] rated short-time withstand current 85 kA (1 s) for 8 supports (lateral position), 75 kA (1 s) for 7 supports (lateral position), 65 kA (1 s) for 5 supports (lateral position), 50 kA (1 s) for 7 supports (rear position), 50 kA (1 s) for 4 supports (lateral position), 40 kA (1 s) for 5 supports (rear position), 40 kA (1 s) for 3 supports (lateral position), 30 kA (1 s) for 4 supports (rear position), 25 kA (1 s) for 3 supports (rear position)
Colour natural
Compatibility code Linergy_busbar
Installation direction vertical, operating position: lateral, vertical, operating position: rear
Permissible current 1480 A at 35 °C: > IP31, 1650 A at 35 °C: <= IP31
[Ie] rated operational current 1600 A
[Ui] rated insulation voltage 1000 V
Busbar cross section 32.5 x 42.5 mm
Connection pitch free connection position
Type of busbar connection single t-slot
[Uimp] rated impulse withstand voltage 12 kV (degree of pollution: 3)
Net weight 4.32 kg
Length 1670 mm
Enclosure/cubicle description cubicle - width 650 + 150 mm, cubicle - width 650 mm
Environment
Standards IEC 61439-1, IEC 61439-2
Product certifications ASTA
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 3.900 cm
Package 1 Width 4.750 cm
Package 1 Length 177.000 cm
Package 1 Weight 3.989 kg
Unit Type of Package 2 2
Number of Units in Package 2 4
Package 2 Height 7.800 cm
Package 2 Width 9.500 cm
Package 2 Length 177.000 cm
Package 2 Weight 15.973 kg
Unit Type of Package 3 3
Number of Units in Package 3 80
Package 3 Height 29.000 cm
Package 3 Width 120.000 cm
Package 3 Length 200.000 cm
Package 3 Weight 339.740 kg
