Picture of Earth-leakage add-on protection module, ComPact NSX 250, MH type, 440 VAC to 550 VAC, 30 mA to 10 A, 4 poles
SKU:

LV431534

Earth-leakage add-on protection module, ComPact NSX 250, MH type, 440 VAC to 550 VAC, 30 mA to 10 A, 4 poles

Old price: $4,668.40 INC GST
$3,818.75 INC GST
Availability: Please contact our sales team on 1300 724 622.
Earth-leakage add-on protection module, ComPact NSX 250, MH type, 440 VAC to 550 VAC, 30 mA to 10 A, 4 poles
Be the first to review this product
Manufacturer: Schneider Electric
Instruction sheet
Catalog
User guide
Product Page Link
Product Data Sheet
It is a MH Vigi add-on module for 4 poles Compact NSX 250 and EasyPact CVS 250. It provides an earth-leakage protection when installed directly on the device terminals. It directly actuates the trip unit in case of insulation fault. The addition of this Vigi add-on module does not modify Compact NSX 250 or EasyPact CVS 250 characteristics. It is a MH type module in 4 poles version, self-powered by the input voltage. The operational voltage for the Vigi add-on is from 440VAC to 550VAC 50/60Hz. The sensitivity is adjustable from 30mA to 10A, the time delay is also adjustable. The dimensions of the circuit breaker equipped with this module are 140mm x 236mm x 86mm.

Products specifications

Attribute name Attribute value
Main
Residual earth-leakage time delay adjustment type adjustable 4 settings
Device application wiring
Earth-leakage add-on module name MH
Poles description 4P
Residual earth-leakage sensitity adjustment type adjustable 5 settings
Range ComPacT
[Δt] residual earth-leakage time delay adjustment 150-150 ms, 310-310 ms, 60-60 ms, 0-0 ms
Product or component type Vigi add-on
Earth-leakage sensitivity 10 A, 3 A, 1 A, 0.3 A, 0.03 A
Earth-leakage protection class class A
Range compatibility ComPact ComPact NSX250 circuit breaker
Range of product ComPact NSX100...250
[In] rated current 250 A
Complementary
Overvoltage category class II
Maximum breaking time 800 ms
Network type AC
Earth-leakage protection with
[Ue] rated operational voltage 440...550 V AC 50/60 Hz conforming to IEC 60947-2
Network frequency 50/60 Hz
Environment
Electrical shock protection class class II
Standards IEC 60947-2
