Picture of END COVER
SKU:

KBA40AF

END COVER

$41.32 INC GST
Available for Shipping : 06-Apr-2026
END COVER
  • Compatible range for lighting systems in small and medium height buildings
  • Modular and upgradeable system
  • Fast and easy mounting solution
  • All components are halogen free, no toxic emission of any fumes in case of fire
  • High protection index IP 55 for all types of buildings
  • Compliant with DALI and KNX communication protocols
  • Dismantled, re-used and entirely recyclable
Be the first to review this product
Manufacturer: Schneider Electric
Delivery date: 06-Apr-2026
Catalog
Instruction sheet
Environmental Disclosure
Product Page Link
Product Data Sheet
This is a end cover for Canalis KBA busbar trunking. Canalis KBA is designed for lighting and power socket distribution. This element is clipped on the end of the line which is not covered by a feed unit. It is a spare part. Canalis KBA is compliant with IEC/EN 61439-6 standard. It is non flame propagating as per the recommendations of IEC 60332-3 standard. All the insulating and plastic materials are halogen free and have enhanced fire withstand capabilities (IEC 60695-2).

Products specifications

Attribute name Attribute value
Main
Product compatibility KBA
Colour white (RAL 9003)
[Ie] rated operational current 40 A
Range Canalis
Product or component type end cover
Offer type spare part
Range of product Canalis
Complementary
Mounting mode by clips
Mounting location side of trunking
Mounting support busbar
Environment
IP degree of protection IP55 conforming to IEC 60529
Standards IEC 60439-2, IEC 61439-6
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 3.000 cm
Package 1 Width 4.500 cm
Package 1 Length 20.700 cm
Package 1 Weight 127.000 g
Unit Type of Package 2 2
Number of Units in Package 2 5
Package 2 Height 6.000 cm
Package 2 Width 12.000 cm
Package 2 Length 21.000 cm
Package 2 Weight 640.000 g
Unit Type of Package 3 3
Number of Units in Package 3 30
Package 3 Height 15.000 cm
Package 3 Width 30.000 cm
Package 3 Length 40.000 cm
Package 3 Weight 4.156 kg
Unit Type of Package 4 4
Number of Units in Package 4 240
Package 4 Height 30.000 cm
Package 4 Width 60.000 cm
Package 4 Length 80.000 cm
Package 4 Weight 40.248 kg
