SKU:

ETS200

Temp Sensor, Strap On, Acc: +/- 0.2 C, 10K Ohm Thermistor, I/NET

$70.33 INC GST

Qty:

Availability: Please contact our sales team on 1300 724 622.

Temp Sensor, Strap On, Acc: +/- 0.2 C, 10K Ohm Thermistor, I/NET

Manufacturer: Schneider Electric

Catalog

Instruction sheet

Product Page Link

Product Data Sheet

Temp Sensor, Strap On, Acc: +/- 0.2 C, 10K Ohm Thermistor, I/NET

Attribute name	Attribute value
Main
Device short name	ETS
Device application	pipe
Depth	29 mm
Temperature resolution	0.1 °C
Colour	cloud white
Output type	resistive output
Width	70 mm
Sensor type	10 kOhm type 2 thermistor temperature
Relative humidity	0-90 % I/NET
Product specific application	for strap-on
Mounting mode	back of stainless steel plate
Function available	high accuracy and interchangeability over wide range, non polarity sensitive
Location	plant room
Product or component type	sensor
Type of measurement	temperature
Targeted region	North America.
Range of product	TAC american sensor
Calibration certificate	none
Height	43 mm
Complementary
Material	metal: enclosure
Connections - terminals	wire (AWG 22)
Environment
Measurement range	- 40...150 °C
Packing Units
Unit Type of Package 1	1
Number of Units in Package 1	1
Package 1 Height	6.096 cm
Package 1 Width	10.668 cm
Package 1 Length	16.256 cm
Package 1 Weight	326.586 g
