Picture of Venta V212 Globe Valve, 2-Way, PN16, Flanged, Balanced Plug, DN50, 38 Kvs, Nodular Iron, Brass Plug, Stem Up Closed.
SKU:

7211244000

Venta V212 Globe Valve, 2-Way, PN16, Flanged, Balanced Plug, DN50, 38 Kvs, Nodular Iron, Brass Plug, Stem Up Closed.

$1,308.01 INC GST
Availability: Please contact our sales team on 1300 724 622.
Venta V212 Globe Valve, 2-Way, PN16, Flanged, Balanced Plug, DN50, 38 Kvs, Nodular Iron, Brass Plug, Stem Up Closed.
  • Balanced valves need less actuator force, for lower cost actuation or a higher close off
  • Self cleaning crown plug design
  • Exceptional control of low flows
  • Unique internal cut out in flange profile aids flexibility against pipe misalignment
  • Bonded gasket improved installation time
  • Replacement gland kit ensures a long operational life
  • U Bolt mounting for MG350, M310, M400, M800, M1500, M700 SR and MG900 SR actuators
Be the first to review this product
Manufacturer: Schneider Electric
Product Page Link
Product Data Sheet
The V212 is a flanged 2-way balanced globe valve designed for a wide range of heating and cooling applications. The balanced plug lowers the actuator force needed for operation, the valve uses a crown plug for precise fluid control. Nodular iron construction provides a long life and high corrosion resistance. The crown plug provides precise fluid control with a rangeability of 5:1 and is of a self cleaning design for reliable operation. Valve size: DN50, ISO Flange Flow capacity, Kvs: 38 m³/h. PN16 pressure class. ΔPm of 4 Kpa. EPDM seals provide a working temperature range of -2 °C to + 12 °C, the soft seat seal ensures a tight close off with no leakage. 2 mm stroke ensures high controllability, Equal percentage flow characteristic ensures high controllability at low opening degrees. Meets the 214/68/EE, article 4.3 of the PED (Pressure Equipment Directive). PN16 flanges have fibre gaskets bonded to the flange face. The flange face has a design that accommodates that flexes to allow small mis alignment in the pipes. A stem heater is available as an accessory for use on media temperature below °C.
