Picture of switch-disconnector I - 2 poles - 100 A
SKU:

15091

switch-disconnector I - 2 poles - 100 A

Old price: $79.97 INC GST
$47.25 INC GST
Availability: Please contact our sales team on 1300 724 622.
switch-disconnector I - 2 poles - 100 A
Be the first to review this product
Manufacturer: Schneider Electric
Product Page Link
Product Data Sheet

Products specifications

Attribute name Attribute value
Main
Device short name I
Device application isolation, control
Poles description 2P
Suitability for isolation yes conforming to IEC 60947-3, yes conforming to EN 60947-3
Utilisation category AC-22A conforming to IEC 60947-3, AC-22A conforming to EN 60947-3
Product or component type switch disconnector
Range of product I
Complementary
[Ue] rated operational voltage 415 V AC 50/60 Hz
Connection pitch 18 mm between phases
[Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60947-3, 6 kV conforming to EN 60947-3
Local signalling ON/OFF indication
Compatibility code I
Mechanical durability 50000 cycles
[Ie] rated operational current 100 A at 415 V AC 50/60 Hz
Tightening torque 3.5 N.m
Colour grey
Electrical durability 10000 cycles
Mounting mode fixed
[Ui] rated insulation voltage 500 V AC 50/60 Hz conforming to IEC 60947-3
Wire stripping length 9 mm
Control type toggle
Connections - terminals tunnel type terminals - 1 x 6...1 x 50 mm² - rigid, tunnel type terminals - 1 x 6...1 x 35 mm² - flexible
9 mm pitches 4
Mounting support DIN rail
Contact position indicator yes
Environment
Pollution degree 3 conforming to IEC 60947-3
IP degree of protection IP4
Tropicalisation 2
Standards IEC 60947-3
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 7.5 cm
Package 1 Width 3.5 cm
Package 1 Length 8 cm
Package 1 Weight 0.152 kg
Unit Type of Package 2 2
Number of Units in Package 2 6
Package 2 Height 7.8 cm
Package 2 Width 8.5 cm
Package 2 Length 22.8 cm
Package 2 Weight 0.97 kg
Unit Type of Package 3 3
Number of Units in Package 3 72
Package 3 Height 30 cm
Package 3 Width 30 cm
Package 3 Length 40 cm
Package 3 Weight 12.127 kg
Unit Type of Package 4 4
Number of Units in Package 4 576
Package 4 Height 50 cm
Package 4 Width 80 cm
Package 4 Length 120 cm
Package 4 Weight 109.96 kg
