SKU:

140NOM25200

DIO head-end adaptor - Modicon Quantum - 1 Modbus Plus fiber optic single copper

$11,833.54 INC GST

Qty:

Available for Shipping : 26-Jan-2026

DIO head-end adaptor - Modicon Quantum - 1 Modbus Plus fiber optic single copper

Manufacturer: Schneider Electric

Delivery date: 26-Jan-2026

CAD

Declaration of conformity

User guide

Catalog

Instruction sheet

Product Page Link

Product Data Sheet

Attribute name	Attribute value
Main
Range of product	Modicon Quantum automation platform
Product or component type	DIO head-end adaptor
Complementary
Bus current requirement	750 mA
Optical transmission	-3.5-110.5 dBm 62.5/125 µm, -19.8--12.8 dBm 50/125 µm, -16--9 dBm 100/140 µm
Power dissipation in W	4 W
Wavelength	820 nm
Minimum pulse width distortion/jitter	5 ns
Dynamic range	20 dB
Checks	checksum, processor, RAM address, RAM
Transmission rate	1 Mbit/s
Number of port	1 Modbus RS232 twisted pair, 1 Modbus Plus fiber optic single copper
Detected silence	-36 dBm
I/O words	30 I/32 O
Rise/fall time	20 ns
Electrical connection	2 connectors TX/RX, 1 connector RJ45
Sensitivity scale	> 30 dBm
Power loss budget	6.5 dB 50/125 µm, 16.5 dB 100/140 µm, 11 dB 62.5/125 µm
Environment
Resistance to electrostatic discharge	8 kV on air conforming to IEC 801-2, 4 kV contact conforming to IEC 801-2
Relative humidity	95-95 % without condensation
Ambient air temperature for storage	-40-85 °C
Resistance to electromagnetic fields	10 V/m 80-2000 MHz conforming to IEC 801-3
Ambient air temperature for operation	0-60 °C
Operating altitude	<= 5000 m
Standards	UL 508
Product certifications	DNV, GOST, C-Tick, RMRS, GL, RINA, CSA Class 1 Division 2
Packing Units
Unit Type of Package 1	1
Number of Units in Package 1	1
Package 1 Height	5.0 cm
Package 1 Width	16.5 cm
Package 1 Length	31.0 cm
Package 1 Weight	494.0 g
