Picture of discrete output module Modicon Quantum - 32 O - 10..30 V DC
SKU:

140DVO85300

discrete output module Modicon Quantum - 32 O - 10..30 V DC

$8,298.58 INC GST
Available for Shipping : 27-Jan-2026
discrete output module Modicon Quantum - 32 O - 10..30 V DC
Be the first to review this product
Manufacturer: Schneider Electric
Delivery date: 27-Jan-2026
CAD
Declaration of conformity
User guide
Catalog
Instruction sheet
Product Page Link
Product Data Sheet

Products specifications

Attribute name Attribute value
Main
Discrete output number 32
Product or component type dc discrete output module
Range of product Modicon Quantum automation platform
Complementary
Maximum tungsten load 6 W 24 V, 3 W 12 V, 2.5 W 10 V
Module format standard
Protection type internal output protection by 5 A fuse per group
Local signalling 32 LEDs (green) for input status, 1 LED (red) for external fault detected (F), 1 LED (green) for bus communication is present (Active)
Fault indication blown fuse, loss of field power, incorrect output state
Addressing requirement 2 input words, 2 output words
Absolute maximum output 50 V for 1 s decaying pulse
Short-circuit protection with
Load inductance inductance(H) = 0.5/((current(A))² x (switching frequency(Hz))) 0.5...4 Hz
Net weight 0.3 kg
Surge current 2.5 A for 1 ms
Output overvoltage protection with
Marking CE
Discrete output voltage 10...30 V DC
Maximum voltage drop <0.4 V 0.5 A
Response time 1 ms at state 1 to state 0, 1 ms at state 0 to state 1, <= 2 ms at state 1 to state 0, <= 2 ms at state 0 to state 1
Bus current requirement 500 mA
Discrete output logic negative logic (sink)
Group of channels 4 groups of 8
Maximum load current <= 4 A each group, <= 16 A per module, <= 0.5 A each point
Power dissipation 2.5 W + (0.1 x all points on) + (0.4 x total load current)
Environment
Operating altitude <= 5000 m
Resistance to electrostatic discharge 8 kV on air conforming to IEC 801-2, 4 kV contact conforming to IEC 801-2
Relative humidity 95-95 % without condensation
Ambient air temperature for storage -40-85 °C
Standards CSA C22.2 No 142, UL 508
Resistance to electromagnetic fields 10 V/m 80-2000 MHz conforming to IEC 801-3
Ambient air temperature for operation 0-60 °C
Product certifications C-Tick, RMRS, FM Class 1 Division 2, GOST
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 16.3 cm
Package 1 Width 4.5 cm
Package 1 Length 31.2 cm
Package 1 Weight 452 g
