Picture of discrete input module Modicon Quantum - 32 I - 24 V DC
SKU:

140DSI35300

discrete input module Modicon Quantum - 32 I - 24 V DC

$4,867.94 INC GST
Available for Shipping : 27-Jan-2026
discrete input module Modicon Quantum - 32 I - 24 V DC
Be the first to review this product
Manufacturer: Schneider Electric
Delivery date: 27-Jan-2026
CAD
Declaration of conformity
User guide
Catalog
Instruction sheet
Product Page Link
Product Data Sheet

Products specifications

Attribute name Attribute value
Main
Discrete input number 32
Product or component type low voltage dc discrete input modules
Range of product Modicon Quantum automation platform
Complementary
Checks broken wire detection
Module format standard
Absolute maximum input 45 V during 10 ms decaying pulse
Local signalling 32 LEDs (green) for input status, 1 LED (red) for external fault detected (F), 1 LED (green) for bus communication is present (Active)
Addressing requirement 4 input words
Bus current requirement 250 mA
Voltage state 1 guaranteed >= 11 V DC
Voltage state 0 guaranteed <= 5 V DC
Net weight 0.3 kg
Isolation between group 500 Vrms for 1 minute
Input voltage limits 20...30 V
Current state 0 guaranteed <= 1.2 mA
Current state 1 guaranteed >= 2.5 mA
Marking CE
Response time 3.3 ms from state 1 to state 0, 2.2 ms from state 0 to state 1
Isolation between group and bus 1780 Vrms for 1 minute
Discrete input voltage 24 V DC
Group of channels 4
Logic input positive (sink)
Environment
Operating altitude <= 5000 m
Resistance to electrostatic discharge 8 kV on air conforming to IEC 801-2, 4 kV contact conforming to IEC 801-2
Relative humidity 95-95 % without condensation
Ambient air temperature for storage -40-85 °C
Standards UL 508, CSA C22.2 No 142
Resistance to electromagnetic fields 10 V/m 80-2000 MHz conforming to IEC 801-3
Ambient air temperature for operation 0-60 °C
Product certifications ABS, C-Tick, FM Class 1 Division 2
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 16.3 cm
Package 1 Width 4.5 cm
Package 1 Length 31.2 cm
Package 1 Weight 429 g
