Picture of discrete input module Modicon Quantum - 16 I - 230 V AC
SKU:

140DAI74000

discrete input module Modicon Quantum - 16 I - 230 V AC

$2,806.01 INC GST
Availability: Please contact our sales team on 1300 724 622.
discrete input module Modicon Quantum - 16 I - 230 V AC
Be the first to review this product
Manufacturer: Schneider Electric
Instruction sheet
User guide
Declaration of conformity
CAD
Catalog
Product Page Link
Product Data Sheet

Products specifications

Attribute name Attribute value
Main
Discrete input number 16
Software name Unity Pro, ProWORX 32, Concept
Product or component type VAC discrete input modules
Range of product Modicon Quantum automation platform
Complementary
Input impedance 31800 Ohm capacitive at 47...53 Hz, 26500 Ohm capacitive at 57...63 Hz
Isolation between channels and bus 1780 Vrms for 1 minute
Maximum leakage current 2.6 mA
Module format standard
Absolute maximum input 400 V 1 cycle, 300 V 10 s, 264 V continuous
Local signalling 16 LEDs (green) for input status, 1 LED (red) for external fault detected (F), 1 LED (green) for bus communication is present (Active)
Addressing requirement 1 input word
Bus current requirement 180 mA
Maximum power dissipation in W 5.5 W
Voltage state 1 guaranteed 175...264 V AC at 47...53 Hz, 165...264 V AC at 57...63 Hz
Isolation between channels 1780 Vrms for 1 minute
Voltage state 0 guaranteed 0...40 V AC at 47...53 Hz, 0...40 V AC at 57...63 Hz
Net weight 0.35 kg
Input current 9.7 mA at 47...53 Hz, 11.5 mA at 57...63 Hz
Marking CE
Network frequency limits 47-63 Hz
Response time 7.3...12.3 ms On-Off, 4.9...0.75 ms x line cycle Off-On
Discrete input voltage 230 V AC
Group of channels 16
Environment
Operating altitude <= 5000 m
Resistance to electrostatic discharge 8 kV on air conforming to IEC 801-2, 4 kV contact conforming to IEC 801-2
Relative humidity 95-95 % without condensation
Ambient air temperature for storage -40-85 °C
Standards CSA C22.2 No 142, UL 508
Resistance to electromagnetic fields 10 V/m 80-2000 MHz conforming to IEC 801-3
Ambient air temperature for operation 0-60 °C
Product certifications cUL, FM Class 1 Division 2
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 16.3 cm
Package 1 Width 4.5 cm
Package 1 Length 31.2 cm
Package 1 Weight 450.0 g
