Picture of power supply module Modicon Quantum - 24 V DC 20..30 V - summable
SKU:

140CPS21400

power supply module Modicon Quantum - 24 V DC 20..30 V - summable

$5,419.81 INC GST
Availability: Please contact our sales team on 1300 724 622.
power supply module Modicon Quantum - 24 V DC 20..30 V - summable
Be the first to review this product
Manufacturer: Schneider Electric
CAD
Instruction sheet
Declaration of conformity
User guide
Catalog
Product Page Link
Product Data Sheet

Products specifications

Attribute name Attribute value
Main
Power supply type summable
Product or component type power supply module
Range of product Modicon Quantum automation platform
Complementary
Input voltage 24 V (20...30 V) DC
Inrush current 25 A 24 V, 14 A 20 V
Module format standard
Output overload protection internal
Local signalling 1 LED (green) for power (PWR OK)
Net weight 0.65 kg
Power supply output current 8-8 A summable
Alarm output 1 NC 6 A 220 V power supply fault
Input current 3800 mA
Associated fuse rating 5 A, slow-blow
Output overvoltage protection internal
Marking CE
Maximum input power interruption 1 ms 20 V, 100 ms
Output voltage 5.1 V DC
Power dissipation 6 + (1.8 x Iout) where Iout is in A
Environment
Operating altitude <= 5000 m
Resistance to electrostatic discharge 8 kV on air conforming to IEC 801-2, 4 kV contact conforming to IEC 801-2
Relative humidity 95-95 % without condensation
Ambient air temperature for storage -40-85 °C
Standards UL 508, CSA C22.2 No 142
Resistance to electromagnetic fields 10 V/m 80-2000 MHz conforming to IEC 801-3
Ambient air temperature for operation 0-60 °C
Product certifications FM Class 1 Division 2, cUL
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 4.83 cm
Package 1 Width 16.51 cm
Package 1 Length 31.5 cm
Package 1 Weight 0.79 kg
Unit Type of Package 2 2
Number of Units in Package 2 7
Package 2 Height 30 cm
Package 2 Width 30 cm
Package 2 Length 40 cm
Package 2 Weight 6169 g
Unit Type of Package 3 3
Number of Units in Package 3 168
Package 3 Height 95 cm
Package 3 Width 80 cm
Package 3 Length 120 cm
Package 3 Weight 157056 g
